SICK Through Beam Photoelectric Sensor, Block Sensor, Detection Range 0 → 2.5 m, PNP Output, Plastic Housing WSE2S-2P3230
Specifications
| Country of Origin | Germany |
|---|---|
| Brand | SICK |
| Response time | 400μs |
| Light Source | Polarised Red Light |
| Detection range | 0 → 2.5 m |
| Model | WSE2S-2P3230 |
| IP Rating | IP67 |
| Mount Type | Threaded, Through Hole |
| Housing Material | Plastic |
| Output type | PNP |
| Series | W2S-2 |
| Maximum Operating Temperature | 50°C |
| Minimum Operating Temperature | -25°C |
| Maximum Current | 50mA |
| DetectIon Type | Through Beam |
| Terminal type | 4-Pin Connector |
| Interface Type | M8 |
| Maximum dc Voltage | 30V dc |
| Hazardous Area Certification | EN IEC 63000 |
| Standards/Approvals | RL, EU, EN IEC 63000 |
| Sensor Style | Block |
| Machine design flexibility | the ultra-compact sensors offer above-average sensing distances and provide space-saving installation |
| Remote setup | sensors installed in confined spaces can be set and monitored remotely via IO-Link |
| High operational reliability | ultrablack objects are detected with a degree of reflection of 1% |
| Quick and easy commissioning | the photoelectric retro-reflective sensor with autocollimation provides a clearly visible light spot for high process reliability |
| Universal application options | wide range of models enclosed in a rugged housing |
| SICK Through Beam Photoelectric Sensor, Block Sensor, 0 → 4.4 m, PNP, IP67Brand | SICK |
Key Features
- The sensor features a block style with through-beam detection for high precision.
- Polarised red light source enables detection of transparent and reflective objects effectively.
- Equipped with a 4-pin M8 connector for reliable electrical connection.
- Operating voltage up to 30 V DC and a maximum current of 50 mA ensure compatibility with industrial systems.
- Durable plastic housing with threaded, through-hole mount offers flexible installation in confined spaces.
- Wide operating temperature range from -25°C to 50°C allows use in various industrial environments.
- IP67 rating protects against dust and water ingress for reliable outdoor and indoor operation.
- Response time is fast at 400 microseconds for high-speed automation applications.
Product Description
SICK WSE2S-2P3230 is a high-performance Through Beam Photoelectric Sensor designed with a block sensor style and a detection range from 0 to 2.5 meters. Featuring a PNP output and housed in robust plastic with IP67 protection, this sensor is suited for demanding industrial automation tasks.
This sensor emits a polarised red light source allowing precise identification of transparent, reflective, and small objects with minimal background interference. The 4-pin M8 connector simplifies electrical integration while the threaded, through-hole mounting provides secure installation even in constrained spaces.
It operates reliably over a wide temperature range (-25°C to 50°C) and supports an operating voltage up to 30 V DC with a maximum current of 50 mA. The device responds rapidly with a response time of 400 microseconds, making it ideal for high-speed production and processing lines.
The WSE2S-2P3230 includes advanced features, such as IO-Link remote setup for sensor configuration and monitoring, supporting flexible machine design and Industry 4.0 requirements. It offers exceptional operational reliability, detecting ultrablack objects with only 1% reflectance and enabling space-saving setups without additional reflectors.
The sensor provides machine design flexibility with ultra-compact size and above-average sensing distances. Remote setup via IO-Link enables configuration in confined and inaccessible locations. High operational reliability detects objects with minimal reflectivity.
Quick and easy commissioning thanks to a clearly visible light spot and autocollimation optics. Universal application suitability due to rugged housing and proven mounting designs. Supports detection tasks in pharmaceutical, logistics, assembly, and manufacturing industries.
Complies with EN IEC 63000 standards for electromagnetic compatibility. Manufactured in Germany ensuring stringent quality and durability standards.
This sensor is widely used in industrial automation, laboratory equipment, manufacturing quality control, and material handling applications. It helps improve precision, reduce false detections, and streamline process efficiency in complex production environments.
Explore the full range of high-quality sensors and automation equipment at EnvMart to optimize your industrial sensing and control operations.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The detection range of this model is from 0 to 2.5 meters.
It features a PNP output type.
The maximum operating voltage for this sensor is 30 V DC.
The response time of the WSE2S-2P3230 is 400 microseconds.
This sensor has an IP67 rating, which protects against dust and water ingress.
It uses a polarised red light source for detection.
The operating temperature range is from -25°C to 50°C.
It features a threaded, through-hole mount for installation.
The sensor is equipped with a 4-pin M8 connector for electrical connection.
It complies with EN IEC 63000 standards for electromagnetic compatibility.
It is suitable for applications in industrial automation, laboratory equipment, and manufacturing quality control.
The housing is made of plastic, providing a rugged design for various environments.
