Igus Chainflex CF140.UL Screened Control Cable, 3 Cores 1mm² 17 AWG, Thermoplastic Elastomer Sheath, 50 CF140.10.03.UL (50m)
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 300, 500V |
| Brand | Igus |
| Model | CF140.10.03.UL (50m) |
| Cable Length | 50m |
| Series | Chainflex CF140.UL |
| Outside diameter | 8.5mm |
| Maximum Operating Temperature | 70°C |
| Number Of Cores | 3 |
| Conductor Material | Copper |
| Minimum Operating Temperature | -15°C |
| Jacket Material | Thermoplastic Elastomer |
| Standards/Approvals | EN, CE |
| Jacket Colour | Grey |
| Fire Behaviour | Flame Retardant |
| American Wire Gauge | 17AWG |
| Screened/Unscreened | Screened |
| Conductor Type | Stranded |
| Cable CSA | 1mm² |
Key Features
- Highly abrasion-resistant thermoplastic elastomer jacket for durability.
- Patented bundled core design allows for small bend radius.
- Armoured and screened for EMI protection and reliable signal transmission.
- Rated for 300 and 500 volts control cable applications.
- Operates at temperatures from -15°C to 70°C suitable for indoor and mild outdoor use.
- Flame retardant and compliant with EN, CE, UL/CSA, and RoHS-II standards.
- Oil resistant class 4 jacket tolerates oils and bio-oils in industrial settings.
- Designed for dynamic e-chain® use with long travel capability up to 400m.
Product Description
Igus CF140.10.03.UL (50m) screened control cable offers a robust solution for automation and control systems requiring reliable and high-performance wiring. With three copper cores of 1mm² cross-sectional area (17 AWG), this cable supports signal transmission with minimal interference.
The thermoplastic elastomer (TPE) jacket provides excellent abrasion resistance and protects against harsh chemical and oil-based environments, making it suitable for industrial setups where durability is critical. The cable is armoured and screened with a low-angled braided screen optimized for continuous flexing applications such as in cable carriers (e-chain®) and automated handling equipment.
This control cable is rated for 300 and 500 volts and operates within a temperature range from -15°C to 70°C, making it applicable to a variety of indoor installations and certain outdoor environments above freezing temperatures. The patented core bundle design allows for very small bending radii, enabling compact installations and reduced wear during movement.
Compliance with flame retardant standards IEC 60332-1-2, CEI 20-35, FT1, VW1, and certifications like UL/CSA styles 10493 and 20200 underline its safety in industrial use. The cable is silicon-free and meets ISO Class 1 cleanroom standards, ensuring suitability for sensitive manufacturing environments.
The cable jacket is oil resistant class 4, resistant to oils and bio-oils prevalent in industrial applications. Its screening effectively guards against electromagnetic compatibility (EMC) issues in complex control environments.
The product is manufactured in Germany, assuring high quality and engineering precision. Proven reliability with over 600 endurance tests in a 2750 m laboratory cycle, backed by a 36-month warranty from Igus.
This product is ideal for industrial automation, packaging machinery, wood and stone processing equipment, and any dynamic or fixed control cable application requiring long service life and high flexibility.
Explore more from Igus and related industrial Control Cables on EnvMart for your automated system needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This control cable is rated for 300 and 500 volts, making it suitable for various control applications.
The maximum operating temperature for this cable is 70°C, allowing it to function in a range of environments.
It features three cores, each with a cross-sectional area of 1mm² (17 AWG).
The jacket is made from thermoplastic elastomer (TPE), providing excellent abrasion resistance and protection against harsh environments.
The outside diameter of the Igus CF140.10.03.UL control cable is 8.5mm.
Yes, it is suitable for mild outdoor use as long as the temperature remains above freezing, operating between -15°C to 70°C.
This model complies with EN, CE, and flame retardant standards like IEC 60332-1-2, ensuring safety in industrial applications.
The cable length is 50 meters, making it suitable for various installations.
The conductors are made of stranded copper, which supports effective signal transmission.
The patented core bundle design allows for very small bending radii, enabling compact installations and reducing wear during movement.
The jacket is oil resistant class 4, making it suitable for environments where exposure to oils and bio-oils is common.
This control cable is manufactured in Germany, ensuring high quality and engineering precision.
