HOBUT Analogue Panel Ammeter 100 A AC, 72 mm x 72 mm, Class 1.5 Moving Iron D72SD

HOBUT D72SD analogue panel ammeter is a high-precision instrument designed for measuring AC current up to 100 A. Featuring a robust moving iron mechanism, this meter offers Class 1.5 accuracy, making it suitable for industrial and commercial electrical applications. The compact 72 mm x 72 mm panel cutout facilitates easy integration into control panels and instrumentation boards. Engineered to operate reliably between -25°C and 40°C, the meter withstands various environmental conditions.

Constructed with a flame retardant case tested to UL 94V0 standards, the ammeter emphasizes safety and durability. It complies with multiple international standards including BS89, CE, DIN 43700, DIN 43802, and IEC 51, attesting to its quality and reliability. The design includes mounting brackets, allowing for straightforward installation. Additionally, this model is compatible with current transformers providing 5 A secondaries and has an overload capacity of 10 times the full scale for short durations.

This Analogue Panel Ammeter finds usage in industrial automation, process control, electrical systems monitoring, and other applications requiring accurate AC current measurement. It is ideal for industries such as manufacturing, HVAC, power generation, and electrical distribution systems.

Moving iron technology for precise current measurements. Class 1.5 accuracy for dependable readings. Panel cutout size 72 mm x 72 mm for standard installations. Wide operating temperature range from -25°C to 40°C. Mounting brackets supplied to facilitate secure panel installation.

Flame retardant housing compliant with UL 94V0 safety standards. Compatible with 5 A secondary current transformers with 10x overload rating. Complies with BS89, CE, DIN, IEC standards for quality assurance. Explore the HOBUT range and other analogue panel instruments across EnvMart for industrial and electrical applications.
