Alpha Wire Grey TEFLON Series 0.33 mm² Silver Plated Copper Hook Up Wire 22 AWG, 19/0.16 mm Strands, 30 m Cable 5875 SL005
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 1kV |
| Brand | Alpha Wire |
| Temperature range | -60°C to +200°C |
| CROSS SECTIONAL AREA | 0.33mm² |
| Model | 5875 SL005 |
| Cable Length | 30m |
| Series | Hookup Wire TEFLON |
| Outside diameter | 1.52mm |
| Maximum Operating Temperature | 200°C |
| Conductor Material | Silver Plated Copper |
| Sub Type | Hookup Wire |
| Cable Type | Hookup |
| Minimum Operating Temperature | -60°C |
| Jacket Material | Polytetrafluoroethylene |
| Wire size | 22 AWG |
| Standards/Approvals | CA Prop 65, MIL-DTL-16878/5 Type EE, NEMA HP3, RoHS Compliant, UL, UL AWM 1180, UR Recognized |
| Jacket Colour | Grey |
| American Wire Gauge | 22AWG |
| Number of Strands | 19 |
| Core Strands | 19 x 0.16mm |
| Size of Strands | 0.16mm |
| Stranding | 19/34 |
| Chemically inert | Chemical and solvent resistance |
| NEMA HP3 Type | EEXBFE |
| Insulation Colour | Slate |
| Grey PVC equipment wire,0.28sq.mm 100mBrand | Brand-Rex |
Key Features
- Constructed with PTFE (Teflon) insulation for excellent chemical and solvent resistance.
- Rated for voltage up to 1 kV and temperature range from -60°C to +200°C.
- Features 19 strands of 0.16 mm diameter silver plated copper wires for flexibility and conductivity.
- Grey jacket color for easy identification in complex wiring systems.
- Compliant with MIL-DTL-16878/5 Type EE, UL AWM 1180, NEMA HP3 standards for military and industrial use.
- Suitable for use in control panels, automotive, electronic equipment, and high temperature ovens.
- Known for superior electrical properties and durability in extreme environments.
Product Description
Alpha Wire 5875 SL005 Hook Up Wire is a high-quality single insulated conductor wire with a cross-sectional area of 0.33 mm² and an American Wire Gauge of 22 AWG. Its conductor is made of silver plated copper stranded as 19 strands of 0.16 mm diameter, which offers excellent flexibility and superior electrical conductivity.
This wire features a polytetrafluoroethylene (PTFE) jacket, commonly known as Teflon, providing outstanding chemical inertness and resistance to solvents. It can reliably operate in extreme temperatures ranging between -60°C and +200°C, making it suitable for harsh industrial and military environments.
The wire's electrical rating supports up to 1 kV, which covers a broad range of low voltage, low current applications. The grey insulation color aids in wiring schemes requiring color coding for identification.
Certified under MIL-DTL-16878/5 Type EE, UL AWM 1180, and NEMA HP3 standards, this hook up wire meets stringent military specifications ensuring durability and safety in demanding applications.
This cable finds extensive use in various industrial and commercial applications including control cabinets, machine tools, high-temperature ovens, automotive electronics, switchboards, transformers, and military equipment. Its resistance to chemicals and solvents combined with excellent electrical properties make it ideal for critical internal wiring tasks in electronic devices and business machines.
Constructed with PTFE insulation offering chemical and solvent resistance. Silver plated copper conductor strands provide high conductivity and flexibility. Rated for 1000 volts and temperature operation from -60°C to 200°C.
Complies with MIL-DTL-16878/5 Type EE, UL AWM 1180, and NEMA HP3 standards. Used in industrial, military, automotive, and electronic internal wiring applications. Grey-colored insulation for easy wire identification. Durable performance under extreme environmental conditions.
Browse Alpha Wire products and similar high-grade Hook Up Wires in the Wires & Cables category at EnvMart to source quality electrical components for your industrial and commercial projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The wire is rated for a voltage of up to 1 kV.
It can operate in a temperature range from -60°C to +200°C.
The cross-sectional area of this hook up wire is 0.33 mm².
This wire consists of 19 strands, each with a diameter of 0.16 mm.
The conductor is made of silver plated copper, and it features a polytetrafluoroethylene (PTFE) jacket.
It complies with MIL-DTL-16878/5 Type EE, UL AWM 1180, and NEMA HP3 standards.
The wire length is 30 meters.
The outside diameter of this hook up wire is 1.52 mm.
The insulation color of this wire is grey.
This wire is suitable for use in control panels, automotive applications, electronic equipment, and high-temperature ovens.
The PTFE insulation provides excellent chemical and solvent resistance, making it suitable for harsh environments.
The wire features a stranding configuration of 19/34.
