Bourdon 100 mm G 1/2 Bottom Pressure Gauge 1 bar MEX5-D30.B15

Bourdon MEX5-D30.B15 100 mm G 1/2 Bottom Pressure Gauge 1 bar is a precision pressure measurement instrument designed for industrial and laboratory applications. It features a 100 mm dial size that ensures readability and a bottom G 1/2 connection allowing for versatile installation options. Constructed with a stainless steel case, it is suitable for corrosive gases and liquids, enhancing longevity and reliability.

The gauge measures pressure ranging from 0 bar minimum up to a maximum of 1 bar, with an accuracy of ±2.5%. It is engineered to operate reliably at temperatures up to 70°C, making it suitable for diverse operational environments. The white dial color coupled with a back entry connection location improves user convenience and installation flexibility.

This MEX5 series pressure gauge also comes with certifications including Lloyds Register Approval and adheres to IP 65 standards for water and dust protection under EN 60529. Compliance with EN 837-1 standards and ATEX II2GDc-IM2c protection ensures safe usage in potentially explosive atmospheres where flammable gases or vapors might be present.

Its wetted parts are made from stainless steel for the MEX model, providing resistance against corrosion from aggressive media. Optional versions for liquid filling and case materials such as 1.4404 (316L) are available for applications exposed to pulsations, vibrations, or aggressive atmospheres.

Common industrial use cases include food and beverage processing, laboratory and medical instruments, oil and gas, chemical processing, water and wastewater treatment, energy production, transportation, logistics, and machinery monitoring systems.

Nominal size dial of 100 mm ensures clear pressure readings. Bottom entry connection with G 1/2 thread size suitable for standard installations. Durable stainless steel case allows use in corrosive environments. Operating temperature up to 70°C accommodates varied industrial conditions.

Accuracy ±2.5% aligns with EN 837-1 class 1 specifications. Approved by Lloyds Register and compliant with IP 65 for protection against dust and water. ATEX II2GDc-IM2c certified for use in hazardous areas with explosive atmospheres.

Versatile for multiple sectors including chemical, oil & gas, and laboratory applications. Explore our comprehensive range of Pressure Gauges at EnvMart for all your industrial measurement needs.
