Bourdon 40 mm G 1/8 Bottom Pressure Gauge 1 bar MAT1-D10.B15
Specifications
| Country of Origin | China |
|---|---|
| Accuracy | ±2.5 % |
| Brand | Bourdon |
| Model | MAT1-D10.B15 |
| Connection Type | Bottom |
| Case Material | Black Painted Steel |
| Series | MAT1 |
| Maximum Operating Temperature | 60°C |
| Dial Size | 40mm |
| Connection Size | G 1/8 |
| Wetted Parts | Brass |
| PRESSURE CONNECTION | G 1/8 |
| Standards/Approvals | EN 837-1 |
| Maximum Pressure Measurement | 1bar |
| Minimum Pressure Measurement | 0bar |
| Connection Location | Bottom Entry |
| Dial Colour | White |
Key Features
- Features a 40 mm white dial for clear pressure readings.
- Accuracy is class 2.5 with ±2.5% tolerance according to EN 837-1 standards.
- Constructed with black painted steel case and brass wetted parts for durability.
- Pressure connection is G 1/8 at the bottom for easy installation.
- Designed for non-corrosive gases and liquids with a maximum operating temperature of 60°C.
- Complies with EN 837-1 standards for industrial quality assurance.
Product Description
Bourdon MAT1-D10.B15 40 mm Bottom Entry Pressure Gauge is designed for accurate pressure measurement up to 1 bar. It features a white dial with clear markings and a black painted steel case providing durability in industrial environments.
This gauge uses brass wetted parts compatible with non-corrosive gasses and liquids, making it suitable for pneumatic and hydraulic applications. The bottom connection type with G 1/8 thread size facilitates straightforward installation in varied systems.
The gauge complies with EN 837-1 standards, guaranteeing compliance with industrial safety and quality requirements. Its operating temperature limit is 60°C, making it ideal for moderate temperature environments in manufacturing, fluid power, and processing industries.
Features a 40 mm white dial for clear pressure readings. Accuracy is class 2.5 with ±2.5% tolerance according to EN 837-1 standards. Constructed with black painted steel case and brass wetted parts for durability. Pressure connection is G 1/8 at the bottom for easy installation.
Designed for non-corrosive gases and liquids with a maximum operating temperature of 60°C. Complies with EN 837-1 standards for industrial quality assurance.
This Bourdon pressure gauge is an industrial-grade instrument essential for accurate measurement and monitoring in manufacturing, laboratory testing, fluid power systems, and HVAC instrumentation. Suitable for use in pneumatic and hydraulic setups, it enhances system control and safety.
Explore Bourdon Pressure Gauges and related measurement instruments in the EnvMart catalog for a comprehensive selection of high-quality industrial devices.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model can measure pressure up to a maximum of 1 bar.
The accuracy of this gauge is class 2.5 with a tolerance of ±2.5% according to EN 837-1 standards.
It features a bottom entry connection type with a G 1/8 thread size for installation.
The case is made of black painted steel, and the wetted parts are constructed from brass.
The maximum operating temperature for this unit is 60°C.
It complies with EN 837-1 standards, ensuring industrial quality assurance.
The dial size of this model is 40 mm, providing clear pressure readings.
It is designed for use with non-corrosive gases and liquids, making it suitable for various applications in pneumatic and hydraulic systems.
The minimum pressure measurement for this gauge is 0 bar.
The bottom entry connection location facilitates straightforward installation in various systems.
This model is part of the MAT1 series of pressure gauges.
Yes, it is essential for accurate measurement and monitoring in manufacturing, laboratory testing, fluid power systems, and HVAC instrumentation.
