Deltron Panel XLR Connector, Straight Orientation, Female, 4 Contacts, Silver Plated, Zinc Alloy Housing, 50V ac 716-0400

Deltron 716-0400 Panel XLR Connector is an industrial-grade female connector designed for reliable audio and video signal transmission in electronics and power connector applications. This straight orientation connector features four contacts rated for 50V ac with a current capacity of 10A, making it ideal for use in commercial and industrial electronics where signal integrity and durability are critical.

The connector's housing is made from rugged zinc alloy diecasting, providing excellent RF protection and mechanical strength. Its silver-plated contacts and brass material ensure superior electrical conductivity and corrosion resistance.

The connector incorporates a unique latching mechanism that requires minimal press action and provides a wide latching area for positive locking and straightforward grounding, enhancing operational reliability in various environments.

Termination is facilitated by screw-type contacts, which accommodate a wide range of cable sizes with generous solder buckets, ensuring easy and secure cable connections. The connector’s thermoplastic insert material offers high mechanical, thermal, and electrical properties, including excellent chemical resistance and dimensional stability.

Operating temperatures range from -25°C to 70°C, supporting diverse industrial and commercial use cases such as mixing desks, tape recorders, video recorders, DAT recorders, and test instrumentation. The compact 31.6mm length allows easy panel mounting with a small industrial standard flange.

Four precision-machined brass contacts with silver plating for connectivity and durability. Rugged zinc alloy housing provides full RF protection and mechanical durability. Screw termination with generous solder buckets for varied cable sizes.

Unique minimal-press latching design for positive locking and grounding. Thermoplastic insert with excellent thermal, mechanical, and chemical resistance. Operational temperature range: -25°C to 70°C for industrial applications.

Current rating of 10A and voltage rating of 50V ac. Compact panel mount connector with a length of 31.6mm and standard flange.

This Deltron panel XLR Connector 716-0400 is manufactured in the United Kingdom and is suitable for use in audio/video electronics, industrial equipment, and test instrumentation requiring robust and reliable connections.
