Deltron Cable XLR Connector, Straight, 50V AC, Female, 5 Way, Silver Plating 708-0500

Deltron 708-0500 Cable XLR Connector is a high-quality 5-way female connector optimized for cable mounting in audio and video systems. Featuring a straight orientation and silver-plated contacts, it ensures low resistance and high-quality signal transmission. The connector operates reliably within a temperature range of -25°C to 70°C and supports a current of 7.5 A at 50V AC voltage rating, making it suitable for both professional and industrial applications.

The connector’s housing is made of durable zinc alloy, providing robustness and resistance to mechanical stress. The assembly and disassembly are screwless and easily achieved by a few quick turns of the back shell, significantly reducing installation time. Its single-piece latch is designed for simple operation and smooth mating with both lockable and non-latching connectors, enhancing operational convenience.

Additionally, the strain relief collet offers a positive cable grip, securing the cable firmly to prevent accidental disconnections. This connector has generous solder buckets, enabling easier cable assembly and accommodating larger conductor sizes. The contact material is brass with silver plating, delivering excellent conductivity and corrosion resistance. The cable termination type is crimp, ensuring a secure electrical connection.

With a length of 71.5 mm, this connector fits well into standard audio/video component setups. Manufactured in the United Kingdom, it offers reliability and conforms to quality manufacturing standards despite having no specific standards/approvals listed.

Supports a current rating of 7.5 A for reliable power transmission. Constructed with a zinc alloy housing providing durable and robust protection. Operates between a temperature range of -25°C to 70°C ensuring stable performance.

Features a screwless assembly with quick-turn back shell for ease of installation and maintenance. Includes a single piece latch for smooth mating with lockable and non-latching connectors. The strain relief collet ensures positive and secure cable grip.

Available in black color with brass contacts providing good conductivity. Termination type is crimp, allowing efficient and strong contact connection. Length of the connector is 71.5mm suitable for various audio/video applications.

Manufactured in the United Kingdom adhering to quality standards.

This Deltron Cable XLR Connector model 708-0500 is especially suited for professional audio, multimedia, and broadcasting environments requiring reliable signal connections. It can be used in industrial, laboratory, and commercial setups where durable and secure AV connectors are needed.
