Molex SL Series Right Angle Through Hole PCB Header, 2 Contact(s), 2.54 mm Pitch, 1 Row, Shrouded 70555-0001

Molex 70555-0001 SL Series Right Angle Through Hole PCB Header is a high-reliability electronic component designed for wire-to-board connections. This single row header features 2 contacts with a standard 2.54 mm pitch and is shrouded to provide added protection and alignment during assembly. It is mounted through-hole style, making it compatible with a variety of PCB designs.

The contact material is brass with a tin plating finish, offering excellent conductivity and corrosion resistance. The thermoplastic housing adds durability while maintaining lightweight characteristics, suitable for portable and handheld electronic equipment.

Rated for a maximum current of 3 amperes and voltage up to 250 volts, this PCB header supports robust electrical performance for various industrial and commercial electronics applications. It operates effectively within a temperature range of -40°C to 105°C, ensuring stability in harsh environments.

The connector system follows wire-to-board protocols with a solder termination type, providing mechanical strength and reliable solder joints. The tail pin length of 3.3 mm facilitates secure mounting on printed circuit boards. The shrouded design includes a large mating guide, enhancing alignment accuracy and ease of assembly.

This component is ideal for industrial, manufacturing, electronics assembly, automation, and laboratory equipment applications where dependable connectivity is critical. Voltage rated up to 250V with current capacity of 3A.

Constructed with thermoplastic housing for durability. Features tin-plated brass male contacts ensuring reliable connection. Operates reliably in temperatures from -40°C to 105°C. Shrouded header design with solder termination for secure mounting.

Ideal for wire-to-board connections in electronics applications. Includes a 3.3 mm tail pin length for stable PCB insertion. Manufactured in the United States, ensuring quality standards. Explore the wide range of Molex PCB Headers on EnvMart for all your high-quality electronic connector requirements.
