Hongfa Europe GMBH PCB Signal Relay 5V DC Coil 2A Switching Current 4PDT Contact Configuration HFD27/024-H
Specifications
| Country of Origin | China |
|---|---|
| Brand | Hongfa Europe GMBH |
| Height | 11.5mm |
| Length | 20.32mm |
| Model | HFD27/024-H |
| Width | 15.24mm |
| Mount Type | PCB |
| Contact Material | Gold Plated |
| Series | HFD27 |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | 4PDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 2A |
| Terminal type | PCB Terminal |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 2.88kΩ |
| Coil Voltage | 5V dc |
| Switching DC Voltage | 220V dc |
| Switching AC Voltage | 250V ac |
| Coil Power | 150mW |
| Switching Power | 60W |
Key Features
- This relay supports switching AC voltage up to 250V AC and DC voltage up to 220V DC.
- Operates reliably within a temperature range of -40°C to 85°C.
- Features gold plated contacts with contact resistance of 100mΩ for superior conductivity.
- Coil resistance is 2.88kΩ with a coil power consumption of 150mW.
- Designed with epoxy sealing suitable for automatic wave soldering and cleaning processes.
- Complies with RoHS standards ensuring environmental safety.
- Ideal for automotive industry control applications and general electromagnetic switching.
- The relay utilizes bifurcated and forcibly guided contacts for reliable switching performance.
Product Description
Hongfa Europe GMBH HFD27/024-H PCB Signal Relay is a subminiature, non-latching electromagnetic relay designed for PCB mounting. This signal relay operates with a 5V DC coil voltage, supporting a maximum switching current of 2A, suitable for both AC and DC applications with voltages up to 250V AC and 220V DC respectively. Its compact size with dimensions 20.32mm (L) × 15.24mm (W) × 11.5mm (H) allows easy integration into densely populated circuit boards.
The relay features high-quality gold plated contacts providing low contact resistance of 100mΩ ensuring efficient signal transfer. Coil resistance of 2.88kΩ and low coil power of 150mW contribute to energy efficiency and sensitive operation. It is encapsulated in epoxy allowing it to endure automatic wave soldering and cleaning processes without damage.
With operational temperature limits from -40°C to 85°C, this relay guarantees reliable performance in harsh industrial and automotive environments. The inclusion of bifurcated contacts and forcibly guided contact design enhances mechanical stability and switching accuracy, reducing the risk of contact welding or bouncing.
This relay series complies with RoHS environmental standards, making it suitable for modern eco-friendly manufacturing requirements. It is ideal for a wide range of industrial uses including control devices and automotive industry applications.
5V DC coil voltage with 2A switching current capability. High switching power capacity up to 60W. Compact PCB mount design with low height profile. Gold plated silver contacts with 100mΩ contact resistance. Epoxy sealed for durability in automated assembly processes.
Wide temperature operating range from -40°C to 85°C. Compliant with RoHS for environmental safety. Bifurcated and forcibly guided contacts for increased reliability. Explore more Signal Relays and PCB mounting components in the Electronics & Electricals category at EnvMart, embracing quality and performance for your precise industrial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum switching voltage of 250V AC and 220V DC.
The relay operates with a coil voltage of 5V DC and has a coil power consumption of 150mW.
The dimensions of this relay are 20.32mm in length, 15.24mm in width, and 11.5mm in height.
This relay features a 4PDT (4 Pole Double Throw) contact configuration.
The contact resistance is 100mΩ, which ensures efficient signal transfer.
It operates reliably within a temperature range of -40°C to 85°C.
This model is designed for PCB (Printed Circuit Board) mounting.
The maximum switching current for this relay is 2A.
Yes, it complies with RoHS standards, ensuring environmental safety.
The coil resistance is 2.88kΩ.
It features gold plated contacts with bifurcated and forcibly guided designs for enhanced reliability and stability.
The maximum switching power capacity is 60W.
