Hongfa Europe GMBH PCB Power Relay 5V dc Coil 20A Switching Current SPDT HF14FW/005-ZSPTF
Specifications
| Country of Origin | China |
|---|---|
| Brand | Hongfa Europe GMBH |
| Height | 26.5mm |
| Length | 29mm |
| Model | HF14FW/005-ZSPTF |
| Width | 13mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | HF14FW |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 20A |
| Terminal type | PCB Pin |
| Contact Resistance | 50mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 47Ω |
| Coil Voltage | 5V dc |
| Switching DC Voltage | 30V dc |
| Switching AC Voltage | 277V |
| Coil Power | 720mW |
| Outline Dimensions | (29.0 x 13.0 x 26.5) mm |
Key Features
- The relay features a Single Pole Double Throw (SPDT) contact configuration.
- It supports a switching DC voltage of up to 30V and AC voltage up to 277V.
- The coil resistance is 47 ohms delivering a coil power of 720mW.
- Operating temperature ranges from -40°C to 85°C for industrial durability.
- Compact dimensions of 29.0 x 13.0 x 26.5 mm enable PCB mounting in space-constrained environments.
- Contacts are made of silver alloy ensuring low contact resistance of 50mΩ for efficient conduction.
- RoHS compliant ensuring environment-friendly manufacturing.
- Suitable for industrial, electrical, automation, and PCB applications.
Product Description
Hongfa Europe GMBH HF14FW/005-ZSPTF PCB Power Relay is a high-quality power relay designed for precise and reliable switching in electrical and automation systems. It operates with a 5V DC coil and supports a significant switching current of 20A, making it ideal for demanding industrial applications.
This relay utilizes a Single Pole Double Throw (SPDT) contact configuration allowing flexible circuit control. It supports switching voltages of up to 30V DC and 277V AC, catering to a wide range of electrical loads.
Constructed for durability, it operates reliably in temperatures ranging from -40°C to 85°C, suitable for harsh environments. The silver alloy contact material minimizes contact resistance to 50mΩ, enhancing performance and longevity.
Compact and easy to mount on PCBs with dimensions of 29.0 x 13.0 x 26.5 mm, it fits well in tightly packed electronic assemblies. The coil resistance of 47Ω and coil power consumption of 720mW ensures energy efficiency during operation.
The product complies with RoHS standards, reflecting its environmentally friendly design. It is widely utilized in industrial automation, electrical control panels, and PCB designs requiring dependable power switching components.
The relay features a Single Pole Double Throw (SPDT) contact configuration. It supports a switching DC voltage of up to 30V and AC voltage up to 277V. The coil resistance is 47 ohms delivering a coil power of 720mW. Operating temperature ranges from -40°C to 85°C for industrial durability.
Compact dimensions of 29.0 x 13.0 x 26.5 mm enable PCB mounting in space-constrained environments. Contacts are made of silver alloy ensuring low contact resistance of 50mΩ for efficient conduction. RoHS compliant ensuring environment-friendly manufacturing.
Suitable for industrial, electrical, automation, and PCB applications. Explore the comprehensive range of Power Relays and PCB components available at EnvMart for your industrial and electrical automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This relay supports a maximum switching current of 20A.
The dimensions of this relay are 29.0 mm in length, 13.0 mm in width, and 26.5 mm in height.
The coil voltage for this model is 5V DC.
It features a Single Pole Double Throw (SPDT) contact configuration.
The operating temperature range is from -40°C to 85°C.
The contacts are made of silver alloy, ensuring low contact resistance.
This relay supports a maximum switching DC voltage of 30V and an AC voltage of 277V.
The coil resistance is 47 ohms.
The coil power consumption is 720mW.
This relay is designed for PCB mounting.
Yes, this relay is RoHS compliant, reflecting its environmentally friendly design.
It is suitable for industrial, electrical, automation, and PCB applications.
