Hongfa Europe GMBH PCB Power Relay 5V DC Coil 30A Switching Current SPDT HF165FD/5-ZY1TF

Hongfa Europe GMBH HF165FD/5-ZY1TF is a PCB mount power relay featuring a 5V DC coil and supports a high switching current of 30A with a Single Pole Double Throw (SPDT) contact configuration. This relay is designed for efficient switching in compact subminiature size, making it suitable for integration in printed circuit boards.

The relay coil consumes 900 mW power with a coil resistance of 27Ω, operating reliably in a temperature range from -40°C to 85°C. Its contacts are made of silver alloy, providing excellent electrical endurance with a low contact resistance of 100 mΩ. The relay supports an AC switching voltage up to 277V and switching power rating of 8.3 kVA, making it adaptable for various power applications.

It has compact physical dimensions of 32.2 mm length, 27.5 mm width, and 20.4 mm height, suitable for space-constrained electronic assemblies. The product is RoHS compliant, emphasizing environmentally friendly manufacturing and reduced hazardous substances.

This relay is built to withstand mechanical stress with a high endurance rating supporting up to 10 million operating cycles, and excellent vibration and abrasion resistance. It offers isolation voltage of 6 kV between coil and contacts and high surge withstand capabilities of up to 6 kV.

Commonly used in industrial machinery, automotive electronics, telecommunications equipment, and household appliances, this relay delivers precise and reliable switching performance in demanding environments.

Designed for PCB mounting with PCB pin terminals. Operates with 5V DC coil voltage and coil resistance of 27Ω. Supports switching AC voltage up to 277V AC and switching power of 8.3 kVA. High electrical endurance with silver alloy contacts and low contact resistance of 100 mΩ.

Wide operating temperature range from -40°C to 85°C. Compact dimensions: length 32.2 mm, width 27.5 mm, height 20.4 mm. Coil power consumption is 900 mW, offering low power operation. Environmentally friendly product compliant with RoHS standards.

High mechanical endurance with lifespan of up to 10 million cycles. Ideal for industrial machinery, telecommunications, automotive, and household appliances control applications. Explore the wide category of Power Relays at EnvMart for more solutions suited to your industrial and electronic system needs.
