Hongfa Europe GMBH PCB Power Relay 12V DC Coil 10A Switching Current SPST HF118F/012-1HS1T(136)
Specifications
| Country of Origin | China |
|---|---|
| Brand | Hongfa Europe GMBH |
| Height | 12.5mm |
| Length | 28.5mm |
| Model | HF118F/012-1HS1T(136) |
| Width | 10.1mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | HF118F |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | PCB Pin |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 620Ω |
| Coil Voltage | 12V dc |
| Switching DC Voltage | 125V dc |
| Switching AC Voltage | 440V |
| Coil Power | 290mW |
Key Features
- This relay features a durable silver alloy contact material ensuring efficient conductivity.
- Operates within a temperature range of -40°C to 85°C for versatile industrial use.
- Offers a coil resistance of 620Ω and coil power of 290mW for stable actuation.
- Supports switching voltages up to 125V DC and 440V AC.
- Compact PCB mount type with dimensions 28.5mm length, 10.1mm width, and 12.5mm height.
- Contact resistance is low at 100mΩ, promoting energy-efficient switching.
- Durability rated up to 1,000,000 operational cycles to ensure long life in industrial settings.
- Meets RoHS compliance standards for environmental safety.
Product Description
Hongfa Europe GMBH HF118F/012-1HS1T(136) is a high-performance PCB power relay featuring a 12V DC coil and SPST contact configuration designed for versatile power switching applications requiring up to 10A switching current.
The relay is constructed with silver alloy contacts to provide reliable and efficient electrical conductivity. Its compact size with dimensions of 28.5mm length, 10.1mm width, and 12.5mm mounting height make it ideal for PCB mounting in constrained spaces.
This device operates reliably within temperatures ranging from -40°C to 85°C and offers a coil resistance of 620Ω and coil power consumption of just 290mW, enabling energy-efficient operation.
It supports switching voltages up to 125V DC and 440V AC, suitable for various electrical loads. The contact resistance is minimized to 100mΩ, reducing energy loss during switching operations.
The HF118F/012-1HS1T(136) relay ensures durability with an operational lifespan of up to 1 million cycles, making it suitable for demanding industrial applications.
Designed to meet RoHS environmental standards, this relay is a reliable component for automotive engines, household appliances, industrial machinery, medical devices, and telecommunications equipment.
This relay features a durable silver alloy contact material ensuring efficient conductivity. Operates within a temperature range of -40°C to 85°C for versatile industrial use. Offers a coil resistance of 620Ω and coil power of 290mW for stable actuation.
Supports switching voltages up to 125V DC and 440V AC. Compact PCB mount type with dimensions 28.5mm length, 10.1mm width, and 12.5mm height. Contact resistance is low at 100mΩ, promoting energy-efficient switching. Durability rated up to 1,000,000 operational cycles to ensure long life in industrial settings.
Meets RoHS compliance standards for environmental safety. Applications include automotive engines, household appliances, industrial machinery, medical equipment, and telecommunication devices. Explore other power relay options in the Electronics & Electricals category on EnvMart to find components suitable for your specific industrial or commercial requirements.
Explore more products in our Power Relays category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay supports a switching current of up to 10A, making it suitable for various power switching applications.
This model has dimensions of 28.5mm in length, 10.1mm in width, and 12.5mm in height, making it compact for PCB mounting.
The coil voltage for this relay is 12V DC, which is necessary for its operation.
It operates within a temperature range of -40°C to 85°C, allowing for versatile use in industrial environments.
The relay features a Single Pole Single Throw (SPST) contact configuration, suitable for basic on/off switching applications.
The contact resistance is low at 100mΩ, which helps to promote energy-efficient switching.
The coil resistance is 620Ω with a coil power consumption of 290mW, ensuring stable actuation.
It supports switching voltages of up to 125V DC and 440V AC, making it versatile for different electrical loads.
The contacts are made from silver alloy, which ensures efficient electrical conductivity.
The relay is rated for up to 1,000,000 operational cycles, ensuring longevity in demanding applications.
Yes, it meets RoHS compliance standards, ensuring it adheres to environmental safety regulations.
This model is designed for PCB mounting, making it suitable for integration into various electronic circuits.
