JST PH Series Vertical Surface PCB Header Crimping Tool, 14 Contacts, 2 mm Pitch, 1 Row, Shrouded B14B-PH-SM4-TB (LF)(SN)

JST B14B-PH-SM4-TB (LF)(SN) is a PH series PCB Header Crimping Tool designed for precise and reliable electrical connections on printed circuit boards. It features 14 contacts arranged in a single row with a 2 mm pitch, ideal for compact and high-density electronic assemblies. The tool supports a vertical, shrouded surface mount header design manufactured with durable polyamide housing, ensuring mechanical stability and insulation performance for demanding industrial applications.

The contact elements are made of copper alloy with gold plating, which provides excellent conductivity and corrosion resistance, enhancing the overall reliability of the wire-to-board connection. Termination is by crimp type and the contact gender is male. This tool is rated for a maximum operating voltage of 100V and continuous current carrying capacity of 2 amperes.

Operating effectively within a temperature range of -25°C to 85°C, the crimping tool is suitable for use in various industrial environments including electronics manufacturing, assembly lines, and prototyping labs. It includes a printed circuit board retention mechanism that secures the header during surface mount assembly.

The compact and low-cost design of this PH series crimping tool makes it an excellent choice for users requiring a reliable and precise PCB header solution with easy integration into automated or manual production processes.

Features 14 contact points ensuring reliable electrical connections. Compact 2 mm pitch and single row configuration suits high-density PCB applications. Constructed with polyamide housing for durable insulation and mechanical stability.

Copper alloy contacts plated with gold for superior conductivity and corrosion resistance. Supports crimp termination type with male contact gender for secure wire-to-board connections. Operates reliably between -25°C to 85°C temperature range.

Designed specifically for vertical mount on PCB surfaces to optimize space and accessibility. Rated for operating voltage up to 100V and current capacity of 2A. Includes a printed circuit board retention mechanism for enhanced stability during assembly.

Manufactured in Japan adhering to high-quality standards.

Ideal for industrial electronics, manufacturing, prototyping, and repair applications where precise and dependable PCB interconnections are required. This crimping tool aligns with industry demands for quality and productivity. Explore more products in the PCB Header category on EnvMart.
