JST XA Series Right Angle Through Hole PCB Header Crimping Tool, 4 Contacts, 2.5 mm Pitch, 1 Row S04B-XASS-1N-BN (LF)(SN)

JST S04B-XASS-1N-BN (LF)(SN) is a high-quality PCB Header Crimping Tool from the XA series, designed for right angle, through hole mounting applications in electronics manufacturing. This crimping tool is engineered to support 4 contacts with a 2.5 mm pitch arranged in a single row, offering secure wire-to-board connections for industrial and electronics assembly use.

The tool features a shrouded design that enhances safety during use by protecting contacts and users alike. It is manufactured with polyamide housing material known for its durability and resistance to wear under mechanical stress.

The contacts are gold-plated copper alloy, ensuring excellent conductivity and resistance to corrosion, which is critical in maintaining integrity in sensitive electronic circuits. Operating temperature range spans from -25°C to 85°C, providing reliable performance in both cold and warm environments.

This crimping tool is compatible with solder termination methods and is suitable for use with automatic board mounting machines. It's rated for 250 volts and a continuous current of 3 amperes, making it ideal for a variety of low voltage electronic applications. The secure locking device and low insertion force design help improve assembly speed and reliability.

Additional features include an insertion guide mechanism to facilitate easy and precise contact placement, as well as a polarizing boss to prevent improper mating of connectors. The tool's tail pin length is 3.4 mm, designed to fit standard PCB footprints accurately.

The tool supports 1 row of contacts and is shrouded for enhanced safety. Constructed with durable polyamide housing material ensuring long-term performance. Gold-plated copper alloy contacts deliver reliable electrical connectivity.

Operates within a temperature range from -25°C to 85°C. Designed for through hole mounting and solder termination, compatible with automatic board mounting. Rated for 250V voltage and 3A current capacity. Features a secure locking device and low insertion force for efficient usage.

Includes an insertion guide mechanism and polarizing boss to prevent incorrect connections.

This JST tool is suitable for use in industrial manufacturing, electronics assembly, and repair applications. It is an essential component for professionals working with PCB connectors requiring precision and reliability.
