Festo Pneumatic Clamping Module EV-20/180-5 with Die-Cast Aluminium Housing and 5 mm Stroke Size EV-20/180-5

Festo EV-20/180-5 pneumatic clamping module is engineered to provide firm and precise clamping of workpieces in industrial environments, particularly suitable for confined installation spaces. Its hydraulic actuation enhances operational consistency and accuracy, removing the need for manual handling during machining or automated processes.

Featuring a robust die-cast aluminium housing, this clamp is both durable and lightweight. It operates effectively within an air pressure range of 2 to 6 bar via an M5 pneumatic connection. The clamp delivers a controlled gripping strength with a stroke size of 5 mm and a clamping area measuring 20 mm by 180 mm.

The pressure chamber utilizes a diaphragm for enhanced sealing and safety, making it ideal for applications requiring hermetic sealing against dust and harsh conditions. The clamp’s block shape and through-hole mounting design allow assembly in any position, increasing its installation flexibility.

The device is rated for ambient temperatures from -20°C to +40°C, meeting strict industry standards including RoHS compliance and ISO8573-1:2010 for pneumatic air quality. It is particularly well-suited for industrial manufacturing, automation systems, and machine tool clamping where safety and efficiency are critical.

Festo’s EV Series clamping modules, including the EV-20/180-5, maintain high reliability and consistent performance in pneumatic air preparation setups. The unit’s hermetic sealing protects internal components, extending operating life in demanding environments.

Die-cast aluminium housing ensures durability and lightweight construction. Operating pressure range from 2 bar to 6 bar suitable for pneumatic applications. M5 pneumatic connection supports easy integration with air systems.

5 mm stroke size with a clamping area of 20 mm x 180 mm for secure gripping. Diaphragm-equipped pressure chamber enhances reliability and safety. Block-shaped clamp with through-hole mount type for versatile assembly positions.

Hermetically sealed for use in harsh and dusty industrial environments. Ambient operating temperature range from -20°C to +40°C. Explore more Pneumatic Air Preparation Accessories and clamps at EnvMart for advanced industrial tooling solutions.
