Fuel And Solvents Unloading Systems
Specifications
| Accuracy | Better Than 0.5% of Reading |
|---|---|
| Display | 8 x 2 Dot Matrix LCD Backlit Display |
| Frequency | 50 Hz |
| Brand | Fluidyne |
| Power Supply | AC 230V |
| Flow | 6000 LPH Max for Gravity Unloading to Underground Tank by Gravity |
| Flow Meter Type | Positive Displacement Rotary Piston |
| Air Separator | Float Actuated Mechanism 1/2"|"| Air Release Port. |
Key Features
- High capacity air separator.
- High accuracy positive displacement flowmeter.
- High capacity float actuated air release mechanism.
- Vacuum Breaker Valve for 100% Air elimination for Underground Tanks
- Back Pressure Valve for 100% Air elimination for above ground Tanks
- Construction ensures system is full of liquid at all times
Product Description
Fuel And Solvents Unloading Systems are specially designed for accurate measurement of liquid fuels and solvents during unloading from tankers to underground as well as above-ground tanks. Accurate measurement of Liquids is the only solution for cross-checking the dip-rod measurement standard on tankers. the system offers excellent protection against pilferage and short supply normally encountered in this application.
- LCD Dot matrix backlit display for easy readability.
- Weather-proof and flame proof electrical fittings.
- RS485 Serial – output for PLC (Optional)
- Resettable and Cumulative display totalisers.
- 10 years memory retention during power failures.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum flow rate for gravity unloading to an underground tank is 6000 LPH.
It uses a positive displacement rotary piston flow meter for accurate measurement.
The system provides an accuracy better than 0.5% of the reading.
It requires an AC power supply of 230V.
Yes, it features an 8 x 2 dot matrix LCD backlit display for easy readability.
It includes weather-proof and flame-proof electrical fittings to enhance safety during operation.
The air separator utilizes a float actuated mechanism with a 1/2" air release port for efficient operation.
The system operates at a frequency of 50 Hz.
Yes, there is an optional serial output for PLC integration.
It features a vacuum breaker valve for 100% air elimination in underground tanks.
For above-ground tanks, it uses a back pressure valve to ensure 100% air elimination.
