Alpha Wire Cable Gland Plug Polyamide, Chloroprene Rubber, Thread Size PG9, Diameter 15 mm, Threaded, IP68, IP66 HPP9 SL080
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 15mm |
| Brand | Alpha Wire |
| Material | Polyamide, Chloroprene Rubber |
| Colour | Grey |
| Temperature range | -20°C to +100°C (Permanent), -30°C to +150°C (Intermittent) |
| Model | HPP9 SL080 |
| IP Rating | IP68, IP66 |
| Series | FIT Wire Management |
| Maximum Operating Temperature | 150°C |
| Thread Size | PG9 |
| Sub Type | Blanking |
| Minimum Operating Temperature | -20°C |
| Thread Length | 6 mm |
| Thread Diameter | 15.2 mm |
| Standards/Approvals | CSA C22.2 Certified, UL 514 Listed, UL 94 V-2 |
| Flammability | V2 (According to UL94) |
| Alpha Wire, PG9 Thread, Plastic, 19 mm Diameter ThreadedBrand | Alpha Wire |
Key Features
- Made from durable Polyamide 6 and Chloroprene Rubber materials for robustness.
- Threaded with size PG9, 15.2 mm thread diameter and 6 mm thread length.
- Provides excellent environmental protection with IP68 and IP66 ratings.
- Operating temperature range from -20°C to 150°C with intermittent tolerance up to 150°C.
- Flame retardant rating of V2 according to UL94 standards.
- Suitable for sealing unused cable gland holes in electrical enclosures.
- Resistant to dust, dirt, sand, and water ingress for harsh industrial environments.
- Certified to CSA C22.2, UL 514, ensuring compliance to safety standards.
Product Description
Alpha Wire HPP9 SL080 cable gland plug is a robust, thread-sized blanking plug designed for sealing cable gland holes where no cables are present, using high-quality Polyamide 6 and Chloroprene Rubber. The PG9 threaded plug features a 15 mm diameter and 6 mm thread length, providing a secure fit for electrical enclosures.
Certified to CSA C22.2, UL 514 Listed, and UL 94 V-2 standards, this cable gland plug offers reliable mechanical protection and flame retardance, rated V2 for stopping flame spread within 30 seconds. It supports an operating temperature range from -20°C to permanent 100°C and up to 150°C for intermittent use.
With IP68 and IP66 ratings, the plug offers superior resistance against dust, dirt, sand, and prolonged water immersion up to 5 bar pressure for 30 minutes, making it suitable for harsh industrial, telecommunications, instrumentation, control systems, and electrical power installations.
The grey Polyamide body provides durability while maintaining flexibility and resistance to environmental degradation. This plug is ideal for use in wire management systems for sealing and protecting unused cable gland openings, enhancing system integrity and safety.
Durable Polyamide 6 and Chloroprene Rubber construction. Thread size PG9 with exact 15.2 mm thread diameter. High ingress protection with IP68 and IP66 ratings. Meets flame retardant standard UL 94 V-2. Temperature rating from -20°C to 150°C (intermittent up to 150°C).
Certified to CSA C22.2 and UL 514 safety standards. Resistant to harmful dust and water immersion. Designed for industrial and electrical cable applications. Grey color for easy identification and installation. Ensures sealing of unused cable gland holes in electrical cabinets.
Explore more Alpha Wire Cable Gland Plugs and fittings at EnvMart for dependable wire management and electrical protection solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The thread size of this model is PG9, with a diameter of 15.2 mm and a thread length of 6 mm.
It is made from Polyamide 6 and Chloroprene Rubber, providing a robust and durable design.
This cable gland plug has IP68 and IP66 ratings, ensuring excellent protection against dust and water ingress.
The operating temperature range is from -20°C to +100°C for permanent use, and it can tolerate up to 150°C for intermittent use.
It is certified to CSA C22.2, UL 514, and meets the flammability standard UL 94 V-2.
The plug is grey in color, which aids in easy identification and installation.
It is designed for sealing unused cable gland holes in electrical enclosures, making it suitable for industrial, telecommunications, and control systems applications.
The flame retardant rating of V2 indicates that it can stop flame spread within 30 seconds, according to UL94 standards.
The IP68 rating signifies that it is resistant to dust and can withstand prolonged water immersion up to 5 bar pressure for 30 minutes.
By sealing unused cable gland openings, it protects against environmental factors, thereby enhancing the integrity and safety of electrical systems.
The maximum operating temperature for intermittent use is 150°C.
The thread diameter of this model is 15 mm.
