Wide Throat Progressive Cavity Screw Pumps Up to 120 m/hr
Specifications
| Capacity | Up to 120 m/hr. |
|---|---|
| Temperature | Up to 150 C / 302 F |
| Viscosity | Up to 30000 cst |
| Pressure Stages | 6 12 18 & 24 Bar |
| Solid Handling Capability | Up to 7% |
Key Features
- High performance
- High Durability
Product Description
Augur-type suction inlet allows in gravity flow of highly viscous material onto augur cum connecting rod which pushes the substance to the pumping element.ExecutionLong life closed or open Cardon Joints / Pin Joints.Reversible flow direction.Suction/delivery standard connections or IDF & option SMS, DIN, JIS Clamp & Ferrule Type.Housing in AISI 304, AISI 316 & AISI 316L. The surface is smooth, eliminating product retaining pockets.Rotor / Shaft & Rotating Parts in AISI 304, AISI 316 & AISI 316LTorsion Free Moulded to Stainless Steel / M.S. Tube Rubber Stator in NCR Food Grade Nitrile, EPDM in white & black color elastomers.Shaft Sealing by Stuffing Box food grade Gland Packed / Mechanical SealApplication:Aluminum / Magnesium Hydroxide Past, Clay Slurry, Explosive Slurry, Formic Acid Slurry, Grease, Green Asbestos Slurry, Grout Mix, High Consistency Paper Pulp, Lecithin, Lithophone Paste, Malt Mix, Minced Meat Mash Grapes, Oil Paste Paint Pre-Mix, Pickle Mix Pigmented Varnish, Putty, Shrikhand, Starch Slurry, Thick Cole Slurry, Undiluted Sludge Yoghurt, Etc.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a maximum capacity of up to 120 m/hr.
This model can handle materials such as aluminum hydroxide paste, clay slurry, explosive slurry, and various food products like minced meat mash and yogurt.
It can manage viscosities of up to 30,000 cst.
The operating temperature range is up to 150°C (302°F).
It is available in pressure stages of 6, 12, 18, and 24 Bar.
The housing can be made from AISI 304, AISI 316, or AISI 316L stainless steel.
Shaft sealing is achieved using a food-grade gland packed stuffing box or a mechanical seal.
It can handle solids up to 7%.
It features long-life closed or open Cardon Joints and Pin Joints.
