Mini Motor MC Reversible Worm AC Geared Motor, 180 W, 3 Phase, 24-Pole, 230 V / 400 V, Flange and Foot MC 440P3T 30 B5

Mini Motor MC 440P3T 30 B5 is a high-quality reversible worm AC geared motor specifically designed for industrial applications requiring controlled torque and speed. It operates on a three-phase power supply of 230 V and 400 V, delivering 180 W of power. The motor’s 24-pole design ensures fine speed regulation with an output speed of 93 rpm, making it ideal for automation and control systems.

Constructed with an aluminum body, this motor is both robust and lightweight, facilitating easy installation and long-term durability. The flange and foot mounting types provide flexibility for various mounting configurations to fit automation and machinery requirements.

The worm gear mechanism efficiently transmits power while minimizing noise and vibration, resulting in reliable and quiet operation. It supports reversible rotation, enhancing adaptability in diverse industrial environments.

This geared motor features a 12.5 mm shaft diameter with a 94 mm shaft length, suitable for coupling with various machinery components. Its compact dimensions - 250 mm length, 95 mm width, and 60 mm depth - allow integration into space-constrained setups.

With a current rating of 520 mA and a maximum output torque of 9 Nm, it offers efficient power consumption and robust performance suitable for demanding applications in electrical, automation, and control gear settings.

The product complies with RoHS standards, assuring environmental safety and regulatory adherence. Originating from Italy, it represents premium manufacturing standards in AC motors and geared drives.

This motor features a 24-pole design for precise speed control. The worm gear type enables high torque transmission with quiet operation. Equipped with flange and foot mounting for versatile installation options. The aluminum construction ensures durability and light weight.

Output speed of 93 rpm and maximum torque of 9 Nm make it suitable for industrial applications. Rotational direction is reversible to adapt to varying operational needs. Shaft diameter is 12.5 mm with a shaft length of 94 mm.

Compact dimensions: length 250 mm, width 95 mm, and depth 60 mm. Current rating of 520 mA ensures efficient power consumption. Complies with RoHS standards and is manufactured in Italy.

This Mini Motor MC series geared motor is perfect for industrial automation, manufacturing machinery, HVAC systems, and other three-phase motor applications. Explore more AC Geared Motors and drive solutions in the Motors & Pumps category on EnvMart.
