Igus Chainflex PVC Control Cable, 2 Cores, 1.5mm², 15 AWG, Unscreened, 25 m Length, Grey Thermoplastic CF130.15.02.UL

Igus CF130.15.02.UL PVC Control Cable is a high-quality control cable designed for medium load applications in industrial and automation settings. This 2-core cable features 1.5mm² cross-sectional area stranded bare copper conductors conforming to EN 60228 standard, which ensures excellent electrical conductivity and flexibility.

The cable is unscreened and has a grey thermoplastic elastomer outer sheath, which offers resistance to oils and abrasion while maintaining a low-adhesion surface ideal for energy chain use. Its flame retardant properties comply with IEC 60332-1-2, CEI 20-35, FT1, and VW1 standards, making it suitable for safe indoor applications.

With a nominal voltage rating of 300 and 500 V, and an outside diameter of 7.5 mm, it supports installation lengths up to 25 meters. The cable is torsion resistant and can be freely suspended or glide along energy chains up to 50 meters, classified as Class 2 for movable cable applications.

The operating temperature range spans from -5°C to a maximum of 70°C, allowing reliable usage under various environmental conditions typically found in manufacturing, industrial automation, and process control environments.

Manufactured in Germany, this control cable meets rigorous EN and CE quality standards. It is particularly suitable for electrical power and industrial cable needs, ensuring safe and efficient transmission of power and control signals.

The cable supports voltages of 300 V and 500 V suitable for power and signal transmission. It has a length of 25 meters with a 7.5 mm outside diameter, providing flexibility in installation. Constructed with fine-wire stranded bare copper conductors for excellent conductivity.

The outer sheath is flame retardant and made of a low-adhesion PVC mixture optimized for energy chains. Operating temperature ranges from -5°C minimum to 70°C maximum ensuring reliable performance under various conditions.

The cable is torsion resistant and preferably used indoors with a flame retardant rating per IEC 60332-1-2 and CEI 20-35 standards. The product is manufactured in Germany adhering to EN and CE standards, assuring quality and safety.

This control cable is ideal for use in industrial, automation, manufacturing, and process control settings. It supports safe and reliable power and data transmission in demanding indoor applications where torsion resistance, flame retardancy, and flexibility are required.
