TE Connectivity Mini-Universal MATE-N-LOK Series Straight Through Hole PCB Header 10 Contacts 4.14 mm Pitch 2 Row 1-770743-1

TE Connectivity 1-770743-1 Mini-Universal MATE-N-LOK Series PCB Header is a precision-engineered wire-to-board connector featuring 10 male contacts in a two-row, 4.14 mm pitch configuration.

The robust white UL94V-0 nylon housing assures flame retardancy, while the gold-plated brass contacts guarantee stable electrical performance and resistance to corrosion. This connector is designed for through-hole mounting with a tail pin length of 3.69 mm suitable for soldering onto PCBs.

Its operating voltage of 600V and current capacity of 9.5A make it suitable for demanding electronic and industrial applications. The operating temperature range spans from -55°C to 105°C, offering reliability across harsh environmental conditions.

The connector's shrouded, straight orientation with a positive locking latch and board locks provides secure mechanical mating and retention on the PCB. This product is ideal for use in industrial control systems, electronic assemblies, and other manufacturing environments requiring dependable PCB connections.

Compared to other connectors, this Mini-Universal MATE-N-LOK series model focuses on compactness, ease of installation, and secure contact integrity, making it a preferred choice for designers and engineers.

This PCB header features a straight through hole mount type for secure board integration. Constructed with a durable nylon housing that is UL94V-0 rated for safety. The 10 male brass contacts are gold plated to ensure excellent conductivity and corrosion resistance.

Designed to operate efficiently in temperatures ranging from -55°C to 105°C. Offers a high voltage rating of 600V and current carrying capacity of 9.5A. Incorporates a positive locking latch mechanism and board locks for secure mating and PCB retention.

Termination is via solder tail with pin length of 3.69 mm for effective soldering. The connector system supports a two-row configuration with 4.14 mm row pitch. Shrouded design enhances safety and prevents incorrect mating.

Ideal for industrial, electronics manufacturing, and assembly applications requiring stable, high-performance PCB connections. Explore the extensive range of TE Connectivity products and PCB connector solutions at EnvMart for engineering, electronics production, and system assembly needs.
