TE Connectivity Mini-Universal MATE-N-LOK Series Straight Through Hole PCB Header, 10 Contacts, 4.14 mm Pitch, 2 1-770743-1

Free Delivery in India | Lowest Global Shipping Charges

TE Connectivity Mini-Universal MATE-N-LOK Series Straight Through Hole PCB Header, 10 Contacts, 4.14 mm Pitch, 2 1-770743-1

Name: TE Connectivity Mini-Universal MATE-N-LOK Series Straight Through Hole PCB Header, 10 Contacts, 4.14 mm Pitch, 2 1-770743-1
Brand: TE Connectivity
SKU: 217827
Price: 5.2 USD
Availability: InStock



Category PCB Connectors & Wire Housings Brand TE Connectivity Condition New

Specifications

Country of Origin	India
Voltage	600V
Brand	TE Connectivity
Orientation	Straight
Current	9.5A
Mount Type	Through Hole
Housing Material	Nylon
Contact Material	Brass
Series	Mini-Universal MATE-N-LOK
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	4.14mm
Contact Plating	Gold
Number of Contacts	10
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Tail Pin Length	3.69mm

Key Features

Constructed with a durable nylon housing for reliable insulation and mechanical stability.
Features 2 rows of contacts arranged with 4.14 mm pitch for precise PCB integration.
Gold-plated brass contacts ensure excellent conductivity and corrosion resistance.
Designed for through-hole mounting with solder termination for secure connection.
Operates within a broad temperature range from -55°C to 105°C for versatile use.
Supports a maximum voltage rating of 600 V and current rating of 9.5 A for demanding electrical applications.
Equipped with a positive locking latch and board locks to enhance retention security on PCBs.
Ideal for industrial, electronic, and power connector applications requiring robust wire-to-board connections.

Product Description

TE Connectivity 1-770743-1 Mini-Universal MATE-N-LOK Series straight through hole PCB header is a precision-engineered connector for wire-to-board interfacing. It features 10 male contacts arranged in 2 rows with a 4.14 mm pitch, housed in a UV-resistant white UL94V-0 nylon casing to ensure durability and electrical insulation.

The connector's brass contacts are gold plated to provide superior conductivity and resistance to corrosion, ensuring long-term performance even in harsh industrial conditions. The solder termination type with 3.69 mm tail pin length offers reliable connection to PCB solder pads.

Designed for through-hole mounting, the header includes a positive locking latch mechanism and PCB retention locks to ensure secure mating and prevent accidental disconnection during operation. Its operating temperature range from -55°C to 105°C makes it suitable for varied environmental conditions.

This connector supports up to 600 V voltage and 9.5 A current, making it compatible with diverse power and electronic circuit requirements. It is widely used in industrial automation, manufacturing equipment, laboratory electronics, and other electronic power distribution systems requiring dependable, high-quality PCB connectors.

Durable nylon housing for electrical insulation and mechanical stability. Gold-plated brass contacts for enhanced conductivity and corrosion resistance. Through-hole mount type with solder termination for secure PCB bonding.

Positive locking latch and board locks for reliable retention. Wide operating temperature from -55°C to 105°C for various industrial environments. Rated for 600 V and 9.5 A ensuring robust electrical performance. 10 contacts arranged in 2 rows with 4.14 mm pitch for precise layout.

This TE Connectivity connector is an essential component in power connectors and PCB connector applications, offering dependable performance for industrial, electronic, and power-related uses. Explore the extensive range of PCB connectors and wire housings to find compatible components for your assembly needs at EnvMart.
