TE Connectivity Power Double Lock Series Male Crimp Terminal 20 AWG Min Crimp 16 AWG Max Contact Tin Plated Copper 177917-1

Free Delivery in India | Lowest Global Shipping Charges

TE Connectivity Power Double Lock Series Male Crimp Terminal 20 AWG Min Crimp 16 AWG Max Contact Tin Plated Copper 177917-1

Name: TE Connectivity Power Double Lock Series Male Crimp Terminal 20 AWG Min Crimp 16 AWG Max Contact Tin Plated Copper 177917-1
Brand: TE Connectivity
SKU: 210914
Price: 0.17 USD
Availability: InStock



Category Power Connector Brand TE Connectivity Condition New

Specifications

Country of Origin	Korea
Brand	TE Connectivity
Current	14A
Model	177917-1
Gender	Male
Contact Material	Copper Alloy
Series	Power Double Lock
Termination Type	Crimp
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-30°C
For Use With	Power Double Lock Connector Housing
Contact Plating	Tin
Minimum Wire Size mm²	0.5mm²
Maximum Wire Size mm²	1.3mm²
Minimum Wire Size AWG	20AWG
Maximum Wire Size AWG	16AWG
Maximum Contact Resistance	20mΩ

Key Features

Constructed from copper alloy for optimal electrical conductivity.
Contact plating is tin to prevent corrosion and ensure reliable connections.
Rated for continuous current of 14 amperes.
Designed to work with Power Double Lock connector housing for secure connections.
Operating temperature range from -30°C to 105°C for versatile applications.
Termination type is crimp, suitable for efficient wiring assembly.
Minimum contact resistance of 20 milliohms reduces power loss.
Suitable for use in refrigerators, air conditioners, washing machines, and other electrical equipment.

Product Description

TE Connectivity 177917-1 Power Double Lock Series male crimp terminal is a high-quality connector component designed for secure and reliable electrical connections in power circuits. It supports wire sizes from 20 AWG (0.5 mm²) to 16 AWG (1.3 mm²) making it versatile for various industrial and commercial wiring applications.

Manufactured from copper alloy with a tin plating finish, this terminal offers excellent electrical conductivity and corrosion resistance ensuring long-term durability and stable current flow rated up to 14 amperes. Its crimp termination type ensures reliable mechanical and electrical connection with minimal assembly time.

The product is compatible with the Power Double Lock connector housing series, facilitating solid engagement and protection against partial contact mating through the use of a double lock plate mechanism. The terminal withstands operating temperatures ranging from -30°C to 105°C, making it suitable for demanding environments such as HVAC systems, refrigeration units, washing machines, and vending machines.

These features make this crimp terminal ideal for power connectors in industrial, manufacturing, HVAC, and appliance sectors. It supports efficient wiring assembly practices and improved safety with its robust design.

Constructed from copper alloy for electrical conductivity and durability. Tinned contact plating ensures corrosion resistance and stable connections. Supports wire sizes between 20 AWG and 16 AWG. Rated current capacity of 14 amperes.

Crimp termination type allows secure wire attachment. Operating temperature range -30°C to 105°C suitable for varied conditions. Compatible with Power Double Lock connector housing. Double lock plate feature prevents incomplete mating of contacts.
