RS PRO 230 V ac 2 x 12 V ac Toroidal Transformer 2 Output 80 VA 671-9113

RS PRO 671-9113 Toroidal Transformer 2 Output 80 VA is a high-quality electrical component designed for efficient power transformation. It operates with a primary voltage of 230 V ac and provides two secondary outputs of 12 V ac each, allowing flexible connection in series, parallel, or as independent outputs.

The toroidal design ensures a compact size with a diameter of 93 mm and a height of 38 mm, making it suitable for installations with limited space. Compared to traditional stacked lamination transformers, this model offers a smaller footprint and reduced weight, weighing approximately 1 kg.

Operating frequencies of 50 Hz to 60 Hz allow compatibility with various power systems. The transformer is constructed with copper conductor terminations and features double insulated primary leads, enhancing both electrical performance and safety standards.

Key features include an extremely low level of radiated magnetic fields and minimal induced noise (hum), along with very low iron losses for high efficiency. The secondary current rating of 3.333 A supports a wide range of electronic and power supply applications.

Although mounting hardware is not supplied, the transformer is designed for easy integration into electronic, industrial, HVAC, and manufacturing environments requiring clean and stable AC power supplies.

Compact toroidal design offers small size and low weight. Dual 115Vac primary windings provide 50/60 Hz operation flexibility. Twin secondary windings can be connected in series, parallel, or used independently. Extremely low level of radiated magnetic fields minimizes interference.

Very low iron loss and induced noise for efficient performance. Termination with copper conductors ensures reliability. High secondary current rating of 3.333 A. Diameter of 93 mm and height of 38 mm for compact installation.

Double insulated primary leads enhance safety. Ideal for electronic, industrial, and power supply applications.

This RS PRO toroidal transformer is a trusted choice for applications requiring robust and efficient AC power transformation. Explore similar transformers in the Toroidal Transformer category on EnvMart for your power supply needs.
