RS PRO 230 V ac 2 x 18 V ac Toroidal Transformer 2 Output 50 VA 671-9104

RS PRO 671-9104 Toroidal Transformer is a dual output toroidal transformer with a primary voltage rating of 230 V ac and two secondary outputs each rated at 18 V ac. With a power rating of 50 VA, this transformer is designed to provide efficient power conversion with minimal noise and magnetic interference.

The toroidal open-wound design uses dual 115 V primary windings allowing flexible configuration options. The secondary windings can be connected in series, parallel, or used independently according to application needs.

This transformer features an 80 mm diameter and is only 33 mm in height, making it compact and suitable for installation in limited spaces. It incorporates copper conductor termination wires for robust and reliable electrical connections.

Its high quality construction results in very low iron loss and a minimal level of hum noise, an essential characteristic for sensitive electronic and industrial applications. The double insulated primary leads add an extra layer of safety against electrical faults.

Key operating parameters include a frequency range from 50 Hz to 60 Hz and a secondary current rating of 1.389 A. Although mounting hardware is not supplied, this toroidal transformer is ideal for use in industrial power supply units, electronic design projects, and various HVAC and manufacturing equipment requiring stable low noise power conversion.

Dual 115 V AC primary windings for 230 V operation. Two secondary outputs rated at 18 V AC each. Compact 80 mm diameter, 33 mm height profile. Copper conductor termination wire for secure connections. 50 VA power rating with 1.389 A secondary current.

Extremely low radiated magnetic field and induced noise. Double insulated primary leads for enhanced safety. Operating frequency of 50 - 60 Hz for versatile applications.

This RS PRO Toroidal Transformer is suitable for various industrial, laboratory, construction, HVAC, and manufacturing contexts where reliable, low-noise power transformation is critical. Explore more transformers and related power supply components at EnvMart to find the best fit for your technical application needs.
