Bourdon 100 mm 1/2 in NPT Bottom Pressure Gauge, 6 bar MEX5-D30.B20
Specifications
| Country of Origin | China |
|---|---|
| Accuracy | ±1 % |
| Brand | Bourdon |
| Model | MEX5-D30.B20 |
| Connection Type | Bottom |
| Case Material | Stainless Steel |
| Series | MEX5 |
| Maximum Operating Temperature | 70°C |
| Dial Size | 100mm |
| Connection Size | 1/2 in NPT |
| PRESSURE CONNECTION | 1/2 inch NPT Male |
| Standards/Approvals | Lloyds Register Approval, EN 837-1, ATEX II2GDc-IM2c |
| Maximum Pressure Measurement | 6bar |
| Minimum Pressure Measurement | 0bar |
| Connection Location | Bottom Entry |
| Dial Colour | White |
Key Features
- Features a durable stainless steel case and fully welded process connection.
- Equipped with a clear white dial face with black lettering for easy readability.
- Operates up to a maximum temperature of 70°C ensuring reliability in various environments.
- Designed with bottom entry 1/2 inch NPT male pressure connection for versatile installation.
- Complies with international standards including EN 837-1 and ATEX II2GDc-IM2c for safety and performance.
- Suitable for use with corrosive gases and liquids in industrial, laboratory, and chemical sectors.
- Incorporates blow out device and elastomer seal for enhanced operator safety.
Product Description
Bourdon MEX5-D30.B20 is a high-quality 100 mm diameter pressure gauge featuring a bottom entry 1/2 in NPT connection and calibrated for pressure measurements up to 6 bar with ±1% accuracy. Designed with a stainless steel case and wetted parts, this gauge ensures durability and resistance to corrosive gases and liquids.
The white dial face with black lettering and black plastic pointer facilitates precise readings, making it ideal for industrial, laboratory, medical, oil, gas, chemical, water treatment, energy, transportation, and machinery applications.
The gauge is compliant with EN 837-1 standards and includes Lloyds Register approval and ATEX certification making it suitable for use in hazardous atmospheres. It features a high-quality instrument glass window with an elastomer seal and a blow out device for operator safety during high-pressure events.
Operating reliably up to 70°C, this pressure gauge supports a bottom connection type that integrates easily into existing piping systems using a 1/2 inch NPT male thread. Features a durable stainless steel case and fully welded process connection.
Equipped with a clear white dial face with black lettering for easy readability. Operates up to a maximum temperature of 70°C ensuring reliability in various environments. Designed with bottom entry 1/2 inch NPT male pressure connection for versatile installation.
Complies with international standards including EN 837-1 and ATEX II2GDc-IM2c for safety and performance. Suitable for use with corrosive gases and liquids in industrial, laboratory, and chemical sectors. Incorporates blow out device and elastomer seal for enhanced operator safety.
This gauge’s robust construction and accuracy class 1.0 compliance make it an essential instrument for precise pressure measurement in industrial plants, HVAC, chemical processing, food and beverage industries, and more.
Explore more Pressure Gauges and related measuring instruments at EnvMart for comprehensive industrial solutions.
