Bourdon 100 mm G 1/2 in Bottom Pressure Gauge 16 bar MIT5-D32.B24

The Bourdon MIT5-D32.B24 pressure gauge is a professional-grade instrument designed for accurate pressure measurement up to 16 bar with a dial size of 100 mm. Featuring a robust stainless steel case and a bottom connection of G 1/2 inch, this gauge adheres to European standards (EN 837-1, NF EN 60529) ensuring dependable performance in industrial and mechanical applications.

The aluminium alloy dial displays clear black graduations on a white background, complemented by a black balanced aluminium pointer for precise reading. The gauge's class 2.5 accuracy offers reliable measurement within ±2.5% to meet operational requirements in demanding environments.

Its cupreous metal Bourdon tube and welded tube connection assembly provide durability and accurate response to pressure changes. The gauge features a 14 mm hexagonal brass connection, suitable for varied equipment setups. The device is suitable for use in compressors, diesel engines, agricultural machinery, public works, machine tools, hydraulic systems, and pumps, conveying versatility across multiple industrial sectors.

Rated IP54 for ingress protection and IP65 for 100 mm diameter models, the gauge withstands typical environmental challenges. It is capable of operating at a maximum temperature of 70°C, making it ideal for a broad range of applications.

The product is manufactured in China and complies with multiple standards including Pressure PED 97/23/CE for safety and regulatory requirements. Features a durable stainless steel case for longevity and reliability. Bottom entry connection with G 1/2 inch size ensures versatile installation options.

Aluminium alloy dial with black graduations on white background for clear readability. Accuracy of ±2.5% consistent with EN 837-1 standards. Operates effectively up to a maximum temperature of 70°C. IP54 rated for protection, with IP65 rating on 100 mm diameter models.

Suitable for compressors, diesel engines, agricultural equipment, hydraulic systems, and pumps. Manufactured conforming to NF EN 60529, EN 837-1, and Pressure PED 97/23/CE standards. Country of origin: China.

The Bourdon pressure gauge series is a reliable choice for industrial, mechanical, and fluid power measurement in pneumatic and hydraulic systems. It is available for viewing and comparison within EnvMart's Pressure Gauges category to assist professionals in equipment selection and system maintenance.
