Bourdon 100 mm G 1/2 Bottom Pressure Gauge 25 bar MEX5-D31.B26
Specifications
| Country of Origin | India |
|---|---|
| Accuracy | ±1 % |
| Brand | Bourdon |
| Model | MEX5-D31.B26 |
| Connection Type | Bottom |
| Case Material | Stainless Steel |
| Series | MEX5 |
| Maximum Operating Temperature | 70°C |
| Dial Size | 100mm |
| Connection Size | G 1/2 |
| PRESSURE CONNECTION | 1/2 inch NPT Male |
| Standards/Approvals | Lloyd's Register approval, EN 837-1, ATEX II2GDc-IM2c |
| Maximum Pressure Measurement | 25bar |
| Minimum Pressure Measurement | 0bar |
| Connection Location | Bottom Entry |
| Dial Colour | White |
Key Features
- Features ±1% accuracy for reliable pressure readings.
- Stainless steel case material ensures durability and corrosion resistance.
- Bottom connection type with G 1/2 and 1/2 inch NPT male thread size.
- Suitable for corrosive gases and liquids with IP65 rating.
- Maximum operating temperature of 70°C allows versatile use.
- Clear white dial with black lettering for easy readability.
- Fitted with instrument glass window, elastomer seal, and blowout device for operator safety.
- Complies with EN 837-1, ATEX II2GDc-IM2c standards and Lloyd’s Register approval.
Product Description
Bourdon MEX5-D31.B26 pressure gauge is a high-quality industrial measuring instrument designed to provide accurate pressure readings in demanding environments. With a 100 mm dial diameter and a maximum pressure measurement of 25 bar, this gauge is suitable for various fluid power and pneumatic & hydraulic applications.
The gauge features a stainless steel case and wetted parts, making it highly resistant to corrosion and suitable for use with corrosive gases and liquids. The white dial with black markings and black plastic pointer ensures excellent visibility and ease of reading measurements.
The connection is a bottom entry type with a G 1/2 connection size and 1/2 inch NPT male thread, allowing secure and reliable installation. It operates reliably up to a maximum temperature of 70°C.
This pressure gauge complies with the strict standards EN 837-1 and ATEX II2GDc-IM2c and has Lloyd’s Register approval, affirming its safety and accuracy. It includes a high-quality instrument glass window, elastomer seal, and blowout device for enhanced operator safety.
Features ±1% accuracy for precise measurement. Stainless steel construction for durability. Bottom connection with G 1/2 size and 1/2 inch NPT male thread. IP65 rated for protection against dust and water ingress. Suitable for food and beverage, laboratory, oil & gas, chemical, water treatment, energy, transportation, and machinery applications.
Easy to read white dial with black markings and black pointer. Compliant with relevant industrial standards and approvals. Includes safety features like blowout device and elastomer seal.
This Bourdon pressure gauge is ideal for use in industrial, laboratory, construction, HVAC, manufacturing, water treatment, agricultural, and commercial settings. It offers reliable performance and long service life in diverse pressure measurement applications.
Explore a wide range of industrial measuring instruments and Pressure Gauges at EnvMart for all your measurement needs.
