Bourdon 50 mm G 1/4 Bottom Pressure Gauge 10 bar MAT2-D20.B22

Bourdon MAT2-D20.B22 50 mm bottom pressure gauge is a high-quality pressure measurement instrument designed to measure pressures up to 10 bar with precision and reliability. Featuring a black painted steel case for protection, this gauge has a white dial with black graduations and a knife edge black aluminium pointer for ease of reading. It complies with EN 837-1 and Pressure PED 97/23/CE standards, ensuring suitability for diverse industrial applications.

This pressure gauge utilizes a cupreous metal Bourdon tube with a welded tube connection assembly and a brass connection with a 14 mm square for secure fitting. Its bottom entry connection type with G 1/4 size provides flexible installation options in compressed gases, lubricating circuits, hot and cold water networks, and water distribution systems.

The gauge is IP32 rated, offering nominal protection from dust ingress and solid objects, and operates reliably at temperatures up to 70°C. Its compact 50 mm dial size makes it suitable for installations where space is limited while maintaining clear readability.

Black painted steel case ensures durability and protection. Accurate pressure reading with ±2.5% accuracy. White dial with knife edge black aluminium pointer for clear visibility. Suitable for compressed gases, lubricating circuits, and water networks.

Complies with EN 837-1 and Pressure PED 97/23/CE standards. Maximum operating temperature of 70°C allows for a range of industrial applications. Bottom entry connection with G 1/4 size for versatile mounting options. Durable cupreous metal Bourdon tube and welded tube connection assembly.

IP32 rated gauge providing basic protection against solid objects. Manufactured in China ensuring consistent quality standards.

This pressure gauge is ideal for industrial, laboratory, HVAC, manufacturing, and water treatment sectors requiring reliable mechanical pressure measurements. Explore the full range of Bourdon pressure measuring instruments and related Pressure Gauges on EnvMart.
