Siemens 3RT2 Contactor 3RT2027-1CL24-3MA0, 230V AC Coil, 3-Pole, 50A, 15 kW 400V, 3 NO, 690V AC
Specifications
| Country of Origin | Germany |
|---|---|
| Brand | Siemens |
| Function | Motor Control |
| Length | 45mm |
| Model | 3RT2027-1CL24-3MA0 |
| Depth | 85mm |
| Width | 140.7mm |
| Mount Type | DIN Rail |
| Series | 3RT2 |
| Power Rating | 15kW |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -25°C |
| Terminal type | Screw Clamp |
| Number of Poles | 3 |
| Standards/Approvals | UL, VDE, CCC, CSA, EAC, RoHS, UKCA |
| Contact Voltage | 690V ac |
| Coil Voltage | 230V ac |
| Normal State Configuration | 3 NO |
| Better World Claim | Low Carbon Manufacture |
| Contact Current | 50A |
| Number of Auxiliary Contacts | 4 |
| Auxiliary Contact Configuration | 2 NO/2 NC |
| Operational Current Ie | 32A |
| Control Circuit Voltage Uc | 400V |
| Contactor Application | Motor Control |
| Pole and Throw Configuration | 3PST |
Key Features
- Operates with a 230V AC coil voltage for reliable switching.
- 3 poles rated for a contact current of 50A.
- Power rating of 15 kW at 400V ensuring efficient performance.
- Equipped with 3 Normally Open contacts for standard motor control.
- DIN Rail mountable for easy installation in control panels.
- Includes 4 auxiliary contacts configured as 2 NO and 2 NC.
- Screw clamp terminal type for secure electrical connection.
- Wide operating temperature range from -25°C to 60°C for versatile use.
Product Description
Siemens 3RT2027-1CL24-3MA0 is a 3RT2 series contactor engineered for industrial motor control applications requiring reliable and efficient switching. It features a 230V AC coil voltage with a robust design suitable for various electrical automation systems. The contactor supports three poles carrying a current of up to 50A and a power rating of 15 kW at 400V, enabling control of medium to high power motors.
This contactor includes 3 Normally Open (NO) contacts complemented by 4 auxiliary contacts configured as 2 NO and 2 NC to expand control options and feedback circuits. It is designed for DIN rail mounting, making it compatible with standard control panel installations and providing installation flexibility.
The device uses screw clamp terminals, ensuring strong and secure electrical connections suitable for demanding environments. Its operational temperature range from -25°C to 60°C allows usage in diverse industrial settings including manufacturing, HVAC, and automation sectors. Compact dimensions (Length: 45 mm, Width: 140.7 mm, Depth: 85 mm) optimize space in equipment assemblies.
Manufactured in Germany, this contactor complies with international safety and performance standards including CE, UL, CSA, CCC, VDE, EAC, RoHS, and UKCA, guaranteeing high quality and durability. The 3RT2 series is climate-proof and suitable for worldwide applications, ensuring reliable motor control across various conditions.
Operates with a 230V AC coil voltage for reliable switching. 3 poles rated for a contact current of 50A. Power rating of 15 kW at 400V ensuring efficient performance. Equipped with 3 Normally Open contacts for standard motor control.
DIN Rail mountable for easy installation in control panels. Includes 4 auxiliary contacts configured as 2 NO and 2 NC. Screw clamp terminal type for secure electrical connection. Wide operating temperature range from -25°C to 60°C for versatile use.
Compact dimensions: Length 45 mm, Width 140.7 mm, Depth 85 mm. Manufactured in Germany adhering to CE, UL, CSA, CCC, VDE, EAC, RoHS, and UKCA standards.
This Siemens 3RT2027-1CL24-3MA0 contactor is ideal for industrial, manufacturing, HVAC, and electrical automation applications where precise and reliable motor control is paramount. Browse EnvMart's comprehensive selection of Contactors for additional options and compatible automation components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The power rating of this contactor is 15 kW at 400V.
It has a maximum contact current rating of 50A.
This unit operates with a coil voltage of 230V AC.
This contactor is designed with 3 poles.
The dimensions are 45 mm in length, 140.7 mm in width, and 85 mm in depth.
It is designed for DIN rail mounting, allowing for easy installation in control panels.
It includes 4 auxiliary contacts configured as 2 Normally Open (NO) and 2 Normally Closed (NC).
The operational temperature range is from -25°C to 60°C.
It complies with several standards including CE, UL, CSA, CCC, VDE, EAC, RoHS, and UKCA.
The contact voltage rating is 690V AC.
It uses screw clamp terminals for secure electrical connections.
This contactor is suitable for motor control applications in industrial, manufacturing, HVAC, and electrical automation sectors.
