Scame Socket Switchable IP44 2+E Pole Earthing Position 6h Straight Industrial Interlock 32A 250V 500.3283

Scame 500.3283 Socket Switchable Industrial Interlock is engineered for reliable, safe power connections in industrial and commercial environments. This straight orientation socket is rated for 32A current at 250V voltage and configured as a 2+E pole format with earthing position at 6h, offering trusted safety compliance.

The body is made of thermoplastic rubber, resistant to abnormal heat and fire up to 650 °C per glow-wire test IEC 60695-2-1, ensuring dimensional stability and durability under continuous operation between -25 °C and +60 °C. Its IP44 rating provides splash-proof protection suitable for harsh environments.

Safety is enhanced via a mechanical interlock system which prevents the switch from closing if the plug is not inserted, extraction of the plug if the switch is closed, and opening of the socket cover if the switch is closed. The socket also features impact resistance tested to 6 Joule rating, stainless steel quick-turning locking screws, and resistance to chemicals such as saline solutions, acids, bases, mineral oils, and weathering.

The product dimensions are 136mm length, 132mm width, and 125mm depth, optimized for surface mounting applications. This socket is manufactured in Italy, under the Scame brand renowned globally for high-quality industrial electrical components.

Industrial use cases include electrical power distribution in manufacturing plants, processing industries, HVAC systems, commercial buildings, and other heavy-duty applications where secure and safe power connectors are essential.

The socket supports 2+E pole format with earthing position at 6h for enhanced safety. Constructed from thermoplastic rubber body material ensuring heat resistance and durability. Features mechanical interlocking to prevent switch closure without plug insertion.

Designed for use in environments requiring protection against splashes (IP44 rated). Impact resistant with a 6 Joule rating for robustness in industrial settings. Dimensions include length 136mm, width 132mm, and depth 125mm for surface mounting.

Equipped with stainless steel quick turning locking screws for secure fixing. Operates safely within temperature ranges from -25 °C to +60 °C. Explore more Scame Industrial Interlocks and related power connectors on EnvMart for reliable and certified industrial electrical solutions.
