RS PRO 230 V ac 2 x 50 V ac Toroidal Transformer 2 Output 1 kVA, EN60065 Class II, EN615581 Class II, UL506 & UL51 123-4006

RS PRO 123-4006 Toroidal Transformer is a high-quality, open style transformer designed for precise power supply needs in industrial and electronic applications. Featuring a primary voltage of 230 V ac and dual secondary outputs at 2 x 50 V ac, this transformer delivers a total power capacity of 1 kVA with a secondary current rating of 12.5 A.

The transformer has a compact form factor with a diameter of 162 mm and a height of 70 mm, enabling flexible mounting options. Its surface mount type design and wire termination facilitate straightforward installation in various setups.

It operates reliably over a frequency range of 50 Hz to 60 Hz and is capable of withstanding temperatures up to 180°C, assuring durability and safety under demanding operating conditions.

Constructed to meet rigorous international standards including EN60065 Class II, EN615581 Class II, UL506, and UL51, this transformer ensures compliance and safety in critical electrical environments.

The RS PRO Toroidal Transformer is ideal for use in industrial machinery, power supply units, electronic devices, and manufacturing equipment requiring stable and isolated power transformation.

Primary voltage rated at 230 V ac for standard power input. Dual secondary voltages of 2 x 50 V ac providing flexible output configurations. Maximum secondary current of 12.5 A ensuring adequate load handling. Compact diameter of 162 mm and height of 70 mm for space-efficient mounting.

Surface mount type with wire termination for easy installation. Operates efficiently between 50 Hz and 60 Hz frequencies. Maximum operating temperature of 180°C suitable for high-demand conditions. Complies with EN60065 Class II, EN615581 Class II, UL506 & UL51 safety standards.

Weight of 6.5 kg supporting robust construction quality. Explore our extensive range of high-quality transformers and electronic components at EnvMart to meet your industrial and commercial needs.
