Belden Cat6 Ethernet Cable, Unshielded Unscreened, 100 m, Grey PVC Cat6 7812E

Belden Cat6 Ethernet Cable 7812E is a premium quality networking cable designed to support high-speed data transfer and communication applications. With a length of 100 meters and a grey PVC jacket, this cable is ideal for use in office networks, data centers, surveillance centers, and building backbone installations.

The cable contains 8 solid copper conductors that are individually insulated with polyethylene to ensure no electrical interference and safe handling. These conductors are twisted in pairs to minimize crosstalk and reduce electromagnetic interference (EMI), delivering noiseless and reliable transmission for category 6 networks and compatible legacy categories such as category 5 and 5 enhanced.

The cable jacket is made from flame-retardant polyvinyl chloride (PVC), protecting the cable against fire hazards and physical damage. It operates efficiently within a wide temperature range of -30°C to +60°C, making it suitable for demanding indoor environments.

This unterminated cable allows users to customize terminations to fit network connectors or devices as needed, offering versatility in installation. It supports data rates up to 1000 Mbps, and is compliant with key standards including European EN 50173-1, ISO/IEC 11801, and US ANSI/TIA/EIA 568-B.2-1.

With a conductor size of 23 AWG and an overall outer diameter of 6.1 mm, the cable provides a robust physical profile suitable for horizontal and backbone wiring, data banks, and surveillance system deployments. Rated for 72 V DC and nominal mutual capacitance of 80 nF/km at 1 kHz, it ensures stable signal integrity over long runs.

This cable features eight solid copper conductors insulated with polyethylene for safe, reliable connectivity. The twisted pair design reduces crosstalk and electromagnetic interference ensuring stable signals. The grey polyvinyl chloride jacket provides flame retardant protection with an operating temperature range from -30°C to 60°C.

Supports category 5, category 5 enhanced, and category 6 applications including Gigabit Ethernet, FDDI, and ATM. Rated for 72 V DC voltage and complies with international and regional standards such as EN 50173-1 and ISO/IEC 11801.

The cable is terminated as unterminated, allowing for custom connector options depending on installation needs. With an outside diameter of 6.1 mm and cable weight of approximately 41 kg/km, it balances flexibility with durability.

Belden’s Cat6 Ethernet Cable 7812E delivers outstanding network performance and reliability for industrial, commercial, and corporate IT infrastructure needs. It is a trusted choice for robust Ethernet installations requiring long cable runs and stable connectivity. Browse more from the Ethernet Cable category at EnvMart for related networking solutions.
