FCT from Molex 15 Way Straight Rear Panel D-Sub Connector Female 2.84 mm Pitch with Flange FM17W2SA-K121 / 1727040018
Specifications
| Country of Origin | Germany |
|---|---|
| Brand | FCT from Molex |
| Orientation | Straight |
| Current | 7.5A |
| Model | FM17W2SA-K121 / 1727040018 |
| Mount Type | Rear Panel |
| Housing Material | Resin Polybutylene Terephthalate |
| Contact Material | Copper Alloy |
| Series | 172704 |
| Mounting Hardware | Flange |
| Termination Type | Solder Cup |
| Maximum Operating Temperature | 130°C |
| Contact Type | Solder Cup |
| Minimum Operating Temperature | -55°C |
| Pitch | 2.84mm |
| Standards/Approvals | EU RoHS China RoHS Compliant with Exemption 6(c) |
| Contact Plating | Gold over Nickel |
| Number of Contacts | 15 |
| Contact Gender | Female |
| Connector Gender | Female |
Key Features
- Features 15 contact points for effective signal transmission.
- Supports a current rating of 7.5A for robust performance.
- Constructed with a resin polybutylene terephthalate housing for durability.
- Gold over nickel plating on copper alloy contacts ensures corrosion resistance.
- Designed with a straight orientation and flange mounting hardware for rear panel installation.
- Operates reliably between -55°C and 130°C temperatures.
- Includes solder cup termination for secure electrical connections.
- Complies with EU RoHS and China RoHS directives with exemption 6(c).
Product Description
FCT from Molex FM17W2SA-K121 / 1727040018 is a 15 Way Straight Rear Panel D-Sub Connector Female designed with a 2.84 mm pitch and flange mounting hardware. It offers reliable electrical and data connection solutions widely used in industrial, electronic, and power connector applications.
The connector features a robust resin polybutylene terephthalate housing that provides high insulation and mechanical strength. Contact points are made of copper alloy plated with gold over nickel, ensuring excellent conductivity and corrosion resistance, critical for long-term performance.
Its straight orientation and flange mount type make the connector well-suited for secure and stable rear panel installations in electronic equipment. The solder cup termination allows for dependable wire connections, facilitating manufacturing and repair workflows.
Operating temperature ranges from -55°C to 130°C enable usage in diverse environments, including industrial equipment, computing devices, and power distribution units. The product adheres to EU RoHS and China RoHS standards, ensuring compliance with environmental and safety regulations.
Features 15 contacts enabling multi-signal transmission. 7.5A current rating suitable for power and data applications. Durable resin housing provides electrical insulation and protection. Gold over nickel plating enhances contact reliability and lifespan.
Flange mounting hardware secures the connector onto panels firmly. Wide temperature operation supports industrial and harsh environments. Solder cup contact termination for reliable wire attachment. Compliant with EU and China RoHS directives for environmental safety.
Mixed contact layout allows versatile connection configurations.
This connector is ideal for use in electronics manufacturing, data communication systems, control panels, and equipment interfacing. Compatible with Molex D-Sub Connector series accessories, it supports customized installations and maintenance efficiency. The German origin underscores quality manufacturing standards and durability.
Explore more connectors and accessories from FCT from Molex in EnvMart for specialized industrial and electronic component needs.
