Advanced Co-axial Binocular Microscope VM-34
Specifications
| Standard Accessories | Include detachable power cable| Cleaning Cloth| Vinyl cover | tissue Paper| blue filter & Oil immersion & User Manual. |
|---|---|
| Model | VM-34 |
| Stages | Built in graduated mechanical stage of 145x125mm. Low coaxial drive controls for easy and smooth scan of specimen slide over range of 50x75mm. |
| Optional Accessories | LED illumination |with battery backup| Wooden box| H15x. |
| Condenser | Moveable Abbe Condenser| NA 1.25 with Iris diaphragm allows precise centering of the light path. |
| Illumination | Built-in White bright LED Illumination system with intensity control regulator | Power Input 220V|A.C|50Hz. |
| Magnification | 100x to 1500x. |
| Objectives | Geooptics DIN Semi Plan Coated Objective 4x| 10x| 40x (s) and 100x (s) Oil Immersion| parafocaled| Anti fungus & anti reflection coated. |
| Focusing | Coaxial coarse & fine focusing mechanism. With stopper to prevent damage to slides or optics. |
| Stand | L Shape Stable & Sturdy metal die cast body & parts with all critical movement. |
| Nosepiece | Quadruple revolving nosepiece ball bearing type. |
| Eyepieces | Widefield eyepiece 10x/ 18mm(paired) | (optional) Huygenian 15x. |
| Observation | Tube Binocular head inclined at 45| rotatable through 360 |Sliding Type |
Key Features
- High Durability
- High performance
Product Description
Advanced Binocular Co-axial Microscope Binocular Head 45 inclined, 360 rotatableDIN Semi Plan Achromatic objectives 4x, 10x, 40x (s) and 100x (s)Coaxial Coarse & Fine focusing mechanismDouble Plate mechanical stageLED illumination for bright and uniform light
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It is equipped with a built-in white bright LED illumination system that includes an intensity control regulator.
The mechanical stage measures 145x125mm and includes low coaxial drive controls for smooth scanning of specimen slides over a range of 50x75mm.
This model includes widefield eyepieces of 10x/18mm (paired), with an optional Huygenian 15x available.
The built-in LED illumination system requires a power input of 220V AC at 50Hz.
It has a moveable Abbe condenser with a numerical aperture of 1.25 and an iris diaphragm for precise light path centering.
The stand is an L-shaped, stable, and sturdy metal die-cast body with all critical movements designed for durability.
The binocular head is inclined at 45 degrees and can rotate through 360 degrees for flexible viewing angles.
Optional accessories include LED illumination with battery backup, a wooden box, and H15x eyepieces.
