Belden 70001NH Series Data Cable 1 Pair 2 Cores 0.9 mm² 120 m Black Sheath Low Smoke Zero Halogen 70001NH.00120

Belden 70001NH.00120 Data Cable is a high-quality twisted pair industrial cable designed for signal transmission in fieldbus and networking systems. It features a 0.9 mm² cross-sectional area with 2 cores arranged as 1 twisted pair over a length of 120 meters. The cable is sheathed with a black Low Smoke Zero Halogen jacket that is flame resistant, ensuring safe operation in hazardous industrial environments. This makes it an excellent choice for installations requiring fire safety and low toxic gas emission in event of fire situations.

The conductors are made of tin copper wire with 7 strands of 26 AWG size providing flexibility and reliable conductivity. The cable has an outside diameter of 8 mm and meets Euroclass Dca standards for fire behaviour. It can withstand operating temperatures from -15°C to 70°C, adaptable to a wide range of industrial conditions.

With a voltage rating of 300 V, this cable is suitable for high-power applications. It features a characteristic impedance of 100 Ω that ensures minimal resistance and strong signal integrity during data transmission. The cable includes inbuilt shielding to protect against electromagnetic interference (EMI), which is critical in industrial automation, telecommunication centers, and computer networking systems.

The maximum pulling tension capacity of 50 N makes this cable resistant to mechanical stress during installation or maintenance. Its robust design and shielded conductors make it reliable for demanding industrial and commercial applications where signal quality and safety are paramount.

This product originates from the Netherlands and is produced by Belden, a recognized leader in high-performance cables. Industrial sectors including automation, telecommunications, and networking will benefit from this cable’s performance and safety features. EnvMart offers this Belden 70001NH Series Data Cable for demanding electrical and automation applications where durability and fire safety are critical.

The cable features a 300V voltage rating suitable for high-power applications. It consists of 2 cores in 1 twisted pair configuration, with 7 strands of 26 AWG tin copper wire per core. The sheath is flame resistant and complies with Euroclass Dca standards ensuring fire safety.

The jacket material is Low Smoke Zero Halogen to reduce toxic emissions in case of fire. The cable has an outside diameter of 8 mm and a black jacket color for easy identification. It operates reliably in temperatures ranging from -15°C to 70°C.

The cable has a characteristic impedance of 100Ω for minimal signal resistance and includes inbuilt shielding to resist electromagnetic interference. With a maximum pulling tension of 50N, the cable is durable and resistant to rough handling.

Explore more cables and wiring products at EnvMart for industrial, electrical, and automation needs from trusted global brands like Belden.
