Bourdon 63 mm Stainless Steel Case Bottom Pressure Gauge 100 bar MEX3-D20.B31

Bourdon MEX3-D20.B31 pressure gauge features a 63 mm nominal dial size with a bottom connection type G 1/4, providing reliable pressure measurement up to 100 bar. The robust stainless steel case and wetted parts ensure resistance to corrosion, making it suitable for use with corrosive gases and liquids in industrial environments.

Its ±1.6 % accuracy complies with EN 837-1 standards, guaranteeing precise readings. The white dial color facilitates easy visibility of measurements. The gauge is rated for a maximum operating temperature of 70°C, allowing for use across a range of industrial and fluid power applications.

This pressure gauge is certified with Lloyds Register Approval, EN 837-1, and ATEX Ex II 2 GDc-IM2c standards, ensuring compliance with rigorous safety and operational requirements. The bottom entry pressure connection enables straightforward installation, making it suitable for industrial pneumatic and hydraulic systems.

With these features, the Bourdon MEX3-D20.B31 is ideal for applications requiring accurate pressure monitoring in aggressive atmospheres or demanding conditions. It is commonly used in industries such as manufacturing, fluid power, HVAC, and chemical processing.

Stainless steel case and wetted parts for corrosion resistance. Accurate pressure measurement with ±1.6 % accuracy. Bottom connection type G 1/4 for easy mounting. Dial size of 63 mm with clear white dial face. Maximum pressure rating of 100 bar for high-pressure systems.

Max operating temperature of 70°C for versatile use. Lloyds Register Approval and ATEX certification for safety. Suitable for pneumatic and hydraulic industrial applications. Explore the full range of Pressure Gauges in EnvMart's extensive catalog for industrial measuring instruments.
