Bourdon 63 mm Stainless Steel Case Bottom Entry Pressure Gauge 4 bar MEX3-D20.B19
Specifications
| Country of Origin | France |
|---|---|
| Accuracy | ±1.6 % |
| Brand | Bourdon |
| Model | MEX3-D20.B19 |
| Connection Type | Bottom |
| Case Material | Stainless Steel |
| Series | MEX3 |
| Maximum Operating Temperature | 70°C |
| Dial Size | 63mm |
| Connection Size | G 1/4 |
| Wetted Parts | Stainless steel |
| PRESSURE CONNECTION | G 1/4 |
| Standards/Approvals | Lloyds Register Approval, EN 837-1, ATEX Ex II 2 GDc-IM2c |
| Maximum Pressure Measurement | 4bar |
| Minimum Pressure Measurement | 0bar |
| Connection Location | Bottom Entry |
| Dial Colour | White |
Key Features
- Equipped with a stainless steel case suitable for corrosive gases and liquids.
- Bottom connection type with G 1/4 size ensuring secure installation.
- Accuracy of ±1.6% as per EN 837-1 standards.
- Maximum operating temperature rated at 70°C for reliable performance.
- Features a white dial color for clear readability.
- Lloyds Register and ATEX Ex II 2 GDc-IM2c approvals ensure compliance with industry standards.
- Designed for industrial and fluid power applications requiring precise pressure measurement.
- Manufactured in France with high-quality stainless steel wetted parts.
Product Description
Bourdon MEX3-D20.B19 pressure gauge features a 63 mm white dial housed in a robust stainless steel case designed for durability and corrosive environments. It has a bottom entry connection type with a G 1/4 connection size, providing reliable integration into various pneumatic and hydraulic systems.
The gauge measures pressure from 0 bar to a maximum of 4 bar with an accuracy of ±1.6% compliant with EN 837-1 standards, ensuring precise and consistent readings for critical industrial operations.
Operating at temperatures up to 70°C, this pressure gauge includes wetted parts made from stainless steel, suitable for handling corrosive gases and liquids commonly encountered in fluid power and mechanical engineering fields.
Certified with Lloyds Register Approval and ATEX Ex II 2 GDc-IM2c, the gauge meets stringent safety requirements, making it ideal for hazardous or explosive environments.
This model belongs to the MEX3 series and offers options such as liquid filling for installations subject to pulsations or vibrations and case material 1.4404 (316L) for more aggressive atmospheres.
Stainless steel case construction for enhanced corrosion resistance. Bottom entry G 1/4 pressure connection for secure mounting. White dial with 63 mm diameter offers excellent visibility. Accuracy tolerance of ±1.6% ensures precise pressure readouts.
Maximum pressure rating of 4 bar suitable for moderate pressure systems. Maximum operating temperature up to 70°C. Lloyds Register and ATEX certifications confirm compliance with industrial safety standards. Made in France guaranteeing premium quality manufacturing standards.
The Bourdon MEX3-D20.B19 pressure gauge is widely used in industrial, laboratory, HVAC, pneumatic, and hydraulic applications where precise pressure monitoring is essential. Its design focuses on long-term reliability and accuracy even in aggressive operating conditions.
Browse more Pressure Gauge models at EnvMart for a comprehensive selection of precision measurement instruments.
