RS PRO Axial Fan, 12V DC, 3W Power, 240mA Max Current, 90 m³/h Air Flow, , 92 x 92 x 25 mm, Ball Bearing, Brushless IP55
Specifications
| Country of Origin | India |
|---|---|
| Power Consumption | 3W |
| Brand | RS PRO |
| Operating Temperature | -10C to +70C |
| Height | 92mm |
| Fan Speed | 2900rpm |
| Air Flow | 90m³/h |
| Model | IP55 |
| Depth | 25mm |
| IP Rating | IP55 |
| Noise Level | 35dB |
| Width | 92mm |
| Series | RS PRO |
| Maximum Current | 240mA |
| Terminal type | Screw |
| Supply Voltage | 12V dc |
| Bearing Type | Ball |
| Standards/Approvals | RoHS |
| Fan Frame Size | 25 mm |
| Fan Frame Type | Square |
| Direction of Curve | Forward |
Key Features
- Operates at 12V DC with 3W power consumption.
- Provides an air flow rate of 90 cubic meters per hour.
- Features a durable polybutylene terephthalate (PBT) frame and impeller.
- Equipped with a brushless DC motor and dual ball bearing for extended life.
- Has an ingress protection rating of IP55 suitable for dusty and wet environments.
- Noise level is low at 35 dB ensuring quiet operation.
- Fan speed is 2900 rpm with a forward curve blade design.
- Includes screw terminal type for secure electrical connections.
Product Description
RS PRO IP55 axial fan combines efficient cooling performance with rugged construction for industrial and commercial applications requiring enclosure ventilation and thermal management.
Powered by 12V DC, this fan uses only 3W of power and generates an air flow of 90 m³/h at a speed of 2900 rpm. It incorporates a brushless DC motor coupled with dual ball bearings to enhance reliability and reduce maintenance needs. The fan's polybutylene terephthalate (PBT) housing and impeller material resist stains and are lightweight, minimizing strain on mounting enclosures.
The IP55 ingress protection ensures robust defense against dust and water jets, allowing use in harsh environments. Its forward curved blades optimize air delivery with minimal noise production, measured at 35 dB for quiet operation. Electrical connections use screw terminals for stable installation. The dimensions are 92 mm by 92 mm with a 25 mm thickness, compatible with standard industrial mounting requirements.
The fan is designed for continuous operation within temperatures ranging from -10°C to +70°C, making it suitable across a wide variety of industrial, electronic, HVAC, and automation sectors. Additional features include impedance protection against motor lock-up and polarity protection to safeguard the motor circuit.
Operates at 12V DC and 3W power consumption. Delivers 90 m³/h air flow ensuring effective ventilation. Brushless DC motor with dual ball bearing for durability and low maintenance. Robust PBT construction with IP55 ingress protection rating.
Quiet operation with noise level at 35 dB. Compatibility with standard enclosures via 92 x 92 x 25 mm dimensions. Forward curved blade design optimizes air flow and efficiency. Temperature operating range from -10°C to +70°C.
Includes screw terminals and polarity protection for safe connections. Impedance protection guards against motor overheating.
This RS PRO axial fan is ideal for industrial automation, electrical enclosures, HVAC systems, and other applications requiring reliable airflow and protection of sensitive equipment. Browse similar RS PRO Axial Fans and related ventilation solutions on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It provides an air flow rate of 90 cubic meters per hour.
The fan operates at a power consumption of 3W.
It can operate within a temperature range of -10°C to +70°C.
It is equipped with a brushless DC motor, which enhances reliability and reduces maintenance needs.
The noise level is low at 35 dB, ensuring quiet operation.
The fan dimensions are 92 mm in width, 92 mm in height, and 25 mm in depth.
It uses dual ball bearings for enhanced durability and low maintenance.
The fan operates at a speed of 2900 rpm.
It includes screw terminal type connections for secure electrical installation.
It has an IP55 ingress protection rating, making it suitable for dusty and wet environments.
The fan features a durable polybutylene terephthalate (PBT) frame and impeller.
This model complies with RoHS standards.
