Belden 1885ELV Cat7 Ethernet Cable 500m Shielded Screened Grey Low Smoke Zero Halogen Cat7

Belden Cat7 Ethernet Cable 1885ELV is a professional-grade, shielded and screened cable designed for demanding industrial, commercial, and infrastructure networking applications. It features a 4-pair configuration with 23 AWG solid bare copper conductors, each pair insulated with foam polyolefin and shielded individually with Beldfoil® foil shielding.

The cable has an overall tinned copper braid shield with 30% coverage to protect against electromagnetic interference and crosstalk, ensuring reliable high-speed data transmission at frequencies up to 1000 MHz. Its Low Smoke Zero Halogen (LSZH) grey jacket enhances safety by limiting toxic fumes and smoke during fire conditions, which is critical for use in confined or public spaces such as data centers, commercial buildings, and industrial facilities.

Belden 1885ELV Cat7 cable is rated for an operating voltage of 72V and a temperature range from -30°C to 60°C, making it suitable for a wide range of environments. It meets international standards EN 50173-1 Ed. 3:2011 and IEC 60332-1 ensuring compliance with industry quality and fire safety requirements.

This cable is supplied unterminated in a 500 meter length reel, allowing installers to cut and terminate according to specific installation requirements for premise horizontal cabling infrastructure. The solid conductor design provides stable connection integrity over extended runs and superior performance for high-speed Ethernet networking.

Constructed with 23 AWG solid bare copper conductors. Each pair shielded with Beldfoil® foil and overall tinned copper braid shield of 30% coverage. Low Smoke Zero Halogen (LSZH) grey jacket for fire safety. Rated for 72V operation over temperature range -30°C to 60°C.

Complies with EN 50173-1 Ed. 3:2011 and IEC 60332-1 standards. Supports data transmission frequencies up to 1000 MHz (Cat7). Supplied in a 500 meter reel, unterminated for flexible installation. Ideal for industrial, commercial, data center, and infrastructure network cabling.
