Alpha Wire FIT Wire Management Grey Chloroprene Rubber Polyamide Cable Gland 3/4 in NPT Thread 13-18 mm PNC3/4 SL080

Alpha Wire PNC3/4 SL080 FIT Wire Management Series grey cable gland is an industrial-grade cable fitting designed for robust strain relief and protection of cables in demanding electrical environments. It features a polyamide 6 body paired with a chloroprene rubber O-ring seal that offers excellent resistance against water, dust, dirt, and sand, meeting IP66 and IP68 ingress protection standards. Its 3/4 inch NPT threaded design ensures versatile mounting compatibility for various cable infrastructures.

The gland accommodates cables with a diameter clamping range between 13 and 18 mm, providing flexibility for multiple wiring configurations. The locknut included allows for secure fastening, reinforcing mechanical integrity under stress and vibration conditions common in industrial installations.

Operating temperature ratings range from a permanent minimum of -20°C to +100°C and can withstand intermittent peaks up to 150°C, making it suitable for high-temperature applications without material degradation. The gland's compliance with CSA and UL 514 certification requirements, as well as UL 94V-2 flammability standard, ensures a high level of electrical safety and fire resistance.

Due to its robust design and reliable sealing performance, this cable gland is suited for use in telecommunications, control and instrumentation systems, electrical power installations, and data cable routing, especially where environmental protection and mechanical strain relief are priorities.

Key features include a thread length of 15 mm and thread diameter of 26.67 mm for secure mechanical connections, along with a slate grey coloration for easy identification and aesthetic integration. The chloroprene rubber provides resilient sealing, ensuring long-term service life even in harsh conditions.

Durable chloroprene rubber seal and polyamide body ensure excellent environmental protection. Wide clamping range for cable diameters 13 mm to 18 mm facilitates versatile application. Locknut included for secure, vibration-resistant fitting installation.

Rated IP66 and IP68 for superior dust and water ingress protection. Operates effectively in temperatures ranging from -20°C to 150°C (intermittent). Certified to CSA, UL 514, and UL 94V-2 standards for safety and flame resistance.

Threaded 3/4 in NPT with 15 mm length and 26.67 mm diameter offers reliable mounting.

This Alpha Wire FIT Wire Management Cable Gland is a dependable solution within industrial, commercial, and utility sectors ensuring secure cable entry with strain relief and protection against environmental and mechanical stresses. Available for purchases through EnvMart, it is an essential component for maintaining system reliability and safety in cable assemblies.
