Alpha Wire FIT Wire Management Series Grey Chloroprene Rubber and Polyamide Cable Gland 1/2 in NPT Thread PNC1/2W SL080
Specifications
| Country of Origin | India |
|---|---|
| Size | NPT-1/2 |
| Brand | Alpha Wire |
| Material | Chloroprene Rubber, Polyamide |
| Colour | Grey |
| Temperature range | -20°C to +100°C (Permanent), -30°C to +150°C (Intermittent) |
| Model | PNC1/2W SL080 |
| IP Rating | IP68, IP66 |
| Series | FIT Wire Management |
| Maximum Operating Temperature | 150°C |
| Thread Size | 1/2 in NPT |
| Minimum Operating Temperature | -20°C |
| Thread Length | 11 mm |
| Clamping Range | 9 - 16 mm |
| Thread Diameter | 21.34 mm |
| Standards/Approvals | CSA, UL 514, UL 94V-2 |
| Maximum Cable Diameter | 14mm |
| Minimum Cable Diameter | 10mm |
| Flammability | V2 (According to UL94) |
Key Features
- Constructed with chloroprene rubber and durable polyamide for robust performance.
- Compatible with cable diameters ranging from 10 mm minimum to 14 mm maximum.
- Equipped with 1/2 inch NPT threaded plastic gland for secure installation.
- IP68 and IP66 rated, providing excellent dust and water resistance.
- Includes locknut for reliable fastening and strain relief.
- Operating temperature from -20°C to 150°C.
- Complies with CSA, UL 514, and UL 94V-2 flammability standards.
- Thread length of 11 mm and thread diameter of 21.34 mm.
Product Description
Alpha Wire PNC1/2W SL080 is a high-quality cable gland from the FIT Wire Management series, designed for managing and protecting cables in demanding industrial and electrical applications. Constructed from grey chloroprene rubber and polyamide, this cable gland provides excellent durability, resistance to environmental factors, and reliable strain relief for cables.
The gland features a 1/2 inch National Pipe Thread (NPT) plastic fitting compatible with cable diameters ranging from 10 mm to 14 mm. The product is IP68 and IP66 certified, ensuring full protection against dust ingress and water immersion up to 5 bar for 30 minutes, making it suitable for harsh environments.
The gland’s operating temperature ranges from -20°C to 150°C with permanent usage up to 100°C and intermittent peaks up to 150°C. It includes a locknut for secure fastening and is compliant with CSA, UL 514, and UL 94V-2 flammability standards (V2 rating indicating flame extinguishing capability within 30 seconds).
This cable gland is ideal for telecommunications, control systems, instrumentation, data transmission, and electrical power wiring, offering robust solutions in industrial, laboratory, construction, HVAC, and manufacturing settings.
Constructed with chloroprene rubber and polyamide for durability and chemical resistance. Safe and reliable strain relief for cables within 10-14 mm diameter range. IP68 and IP66 rated for dust and water ingress protection.
Operating temperature from -20°C to 150°C suitable for various environments. Includes locknut for firm installation and improved safety. Complies with industry-standard CSA, UL 514, and UL 94V-2 certifications. Thread length of 11 mm and thread diameter of 21.34 mm for standard fittings.
Embrace reliable cable management and protection with Alpha Wire’s PNC1/2W SL080 cable gland, engineered for demanding environments and rigorous industrial use. Browse more cable glands and cable management components in the Cable Gland category on EnvMart for your precise requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model accommodates cable diameters ranging from 10 mm minimum to 14 mm maximum.
It is rated IP68 and IP66, providing excellent protection against dust ingress and water immersion.
The cable gland is constructed from chloroprene rubber and durable polyamide.
The operating temperature ranges from -20°C for permanent use, with intermittent peaks up to 150°C.
It features a 1/2 inch NPT threaded design.
Yes, it includes a locknut for secure fastening and strain relief.
The thread length is 11 mm, and the thread diameter is 21.34 mm.
It complies with CSA, UL 514, and UL 94V-2 flammability standards.
The clamping range for this model is between 9 mm and 16 mm.
This cable gland is suitable for telecommunications, control systems, instrumentation, data transmission, and electrical power wiring.
The maximum operating temperature is 150°C.
The country of origin for this product is India.
