APEM AV Series Illuminated Momentary Push Button Switch Green LED, SPST, Flat Actuator, IP65, 250 V ac AV09C7L3D9403K

APEM AV Series Illuminated Push Button Switch model AV09C7L3D9403K offers robust performance with a momentary SPST switch mechanism and green LED illumination, designed for demanding industrial and automation applications.

This switch features a 19.2 mm panel cutout and a flat silver actuator providing tactile feedback for precision actuation. Its IP65 ingress protection rating ensures strong resistance to dust and water ingress, making it suitable for harsh industrial environments including manufacturing, control panels, and automation equipment.

The contact configuration provides Single Pole Single Throw (SPST) momentary ON switching functionality to meet control requirements. The LED illumination is powered by a 3V DC, 10 mA supply, providing clear visual indication of switch status with a green light ring.

Manufactured with stainless steel or nickel plated brass components, the switch combines durability and corrosion resistance to withstand extensive usage. It supports panel thicknesses up to 6 mm, making it adaptable to a variety of mounting scenarios.

Rated for operation at 250 V AC with a contact current of 50 mA, this switch is designed for integration into electrical and automation systems requiring reliable control input.

With an operating temperature range from -30°C to 70°C and a service life of one million cycles, the AV Series switch ensures dependable operation in both moderate and extreme industrial conditions.

Common applications include industrial control systems, machine automation, electrical panels, HVAC controls, and laboratory equipment where precise momentary push button activation and illumination feedback are essential.

The switch features a silver flat actuator with tactile feedback for comfortable operation. Contact configuration is Single Pole Single Throw (SPST) with momentary ON operation. Designed with a panel cutout size of 19.2 mm to fit standard mounting panels.

The IP65 rating ensures dust-tight and water-resistant performance for harsh environments. Operates at 250 V AC voltage with a contact current rating of 50 mA. Equipped with a green illuminated LED ring requiring a 3V DC, 10 mA supply.

Constructed with stainless steel or nickel plated brass for robust durability and corrosion resistance. Suitable for panel thickness between 1 to 6 mm for versatile mounting options. Rated for a service life of 1 million operations, providing reliable long-term usage.

Operating temperature range extends from -30°C to 70°C, accommodating wide ambient conditions.

This product is ideal for users in industrial, laboratory, electrical control, and automation sectors requiring a high-quality illuminated push button switch with assured longevity and environmental protection.
