Bourdon 63 mm Stainless Steel Case Bottom Entry Pressure Gauge 40 bar MIT3-D22.B27

Free Delivery in India | Lowest Global Shipping Charges

Bourdon 63 mm Stainless Steel Case Bottom Entry Pressure Gauge 40 bar MIT3-D22.B27

Name: Bourdon 63 mm Stainless Steel Case Bottom Entry Pressure Gauge 40 bar MIT3-D22.B27
Brand: Bourdon
SKU: 145284
Price: 32.01 USD
Availability: InStock



Category Pressure Gauges Brand Bourdon Condition New

Specifications

Country of Origin	China
Accuracy	±2.5 %
Brand	Bourdon
Model	MIT3-D22.B27
Connection Type	Bottom
Case Material	Stainless Steel
Series	MIT3
Maximum Operating Temperature	70°C
Dial Size	63mm
Connection Size	G 1/4
PRESSURE CONNECTION	Brass
Maximum Pressure Measurement	40bar
Minimum Pressure Measurement	0bar
Connection Location	Bottom Entry
Dial Colour	White, Black

Key Features

The gauge features a brass G 1/4 bottom connection ensuring durability and secure fitting.
It has an accuracy class of ±2.5%, meeting industry standards.
The white dial with black graduations and pointer provides clear readability.
Maximum operating temperature is 70°C, suitable for various industrial environments.
The gauge complies with standards including Pressure PED 97/23/CE and EN 837-1.
Its cupreous metal Bourdon tube and welded tube connection ensure performance reliability.
IP54 protection rating guards against dust and splashing water.
Ideal for applications in compressors, diesel engines, agricultural equipment, and hydraulic systems.

Product Description

The Bourdon MIT3-D22.B27 pressure gauge is a high-quality instrument designed for precise pressure measurement up to 40 bar. It features a 63 mm diameter dial housed in a robust stainless steel case. Its bottom entry brass connection (G 1/4) offers a secure and stable installation point in various hydraulic and pneumatic systems.

The dial presents clear black graduations and numbers on a white background, complemented by a black balanced aluminium pointer, facilitating easy reading. This gauge maintains an accuracy of ±2.5%, classified as Class 2.5 according to EN 837-1 standards, ensuring reliability in demanding industrial environments.

Constructed with a cupreous metal Bourdon tube and a welded tube connection assembly, the gauge provides durability and longevity. The 14 mm hexagonal brass connection ensures compatibility with standard piping. Rated IP54 for dust and water protection, this model is suitable for applications involving exposure to challenging conditions.

Operating temperatures up to 70°C and compliance with Pressure PED 97/23/CE and NF EN 60529 make the Bourdon MIT3-D22.B27 suitable for a diverse range of industrial contexts including compressors, diesel engines, agricultural machinery, public works, machine tools, hydraulic systems, and pumps.

The gauge features a brass G 1/4 bottom connection ensuring durability and secure fitting. It has an accuracy class of ±2.5%, meeting industry standards. The white dial with black graduations and pointer provides clear readability.

Maximum operating temperature is 70°C, suitable for various industrial environments. The gauge complies with standards including Pressure PED 97/23/CE and EN 837-1. Its cupreous metal Bourdon tube and welded tube connection ensure performance reliability.

IP54 protection rating guards against dust and splashing water. Ideal for applications in compressors, diesel engines, agricultural equipment, and hydraulic systems.

This pressure gauge is an essential instrument for precise monitoring in industrial, laboratory, hydraulic, agricultural, and manufacturing applications. For more options and related instruments, explore EnvMart’s comprehensive Pressure Gauges category.
