Bourdon 100 mm G 1/2 in Bottom Pressure Gauge 4 bar MAT5-D30.B19

The Bourdon MAT5-D30.B19 is a 100 mm diameter pressure gauge featuring a G 1/2 inch bottom connection. Designed with a durable black painted steel case and an ABS plastic dial, this gauge provides accurate pressure measurements up to 4 bar with ±2.5% accuracy. The white dial with clear graduations and a knife edge black aluminium pointer ensures precision readings for a variety of industrial applications.

Constructed with a cupreous metal Bourdon tube and brass connection with 14 mm square, this pressure gauge delivers reliable performance in compressed gases, lubricating circuits, hot or cold water networks, and water distribution systems. Its case and dial materials provide robustness suitable for environments up to 70°C operating temperature, while the IP32 rating offers protection against ingress.

Manufactured to conform to EN 837-1 and PED 97/23/CE standards, this pressure gauge assures quality and compliance. The gauge's bottom entry connection location enables flexible installation. Available in various dial sizes including 40, 50, 63, and 100 mm, the MAT series suits multiple measuring needs.

Features a black painted steel case for durability. White dial face with easy-to-read black graduations and numbers. Connection size G 1/2 inch at the bottom entry for versatile installation. Accuracy class of ±2.5% ensures reliable pressure readings.

Maximum operating temperature up to 70°C suitable for various environments. Complies with EN 837-1 and PED 97/23/CE standards for safety and performance. Equipped with a knife edge black aluminium pointer for precision. IP32 rating for protection against ingress of foreign objects.

Applications include compressed gases, lubricating circuits, and water distribution systems. Manufactured to meet industrial requirements with a cupreous metal Bourdon tube and brass fittings.

This Bourdon Pressure Gauge MAT5-D30.B19 is ideal for industrial, fluid power, and mechanical instrumentation sectors requiring accurate and robust pressure monitoring. Explore EnvMart's extensive catalog of pressure measurement instruments and gauges for enhanced industrial instrumentation.
