Bourdon 63 mm G 1/4 Bottom Pressure Gauge, 6 bar MAT3-D20.B20

Free Delivery in India | Lowest Global Shipping Charges

Bourdon 63 mm G 1/4 Bottom Pressure Gauge, 6 bar MAT3-D20.B20

Name: Bourdon 63 mm G 1/4 Bottom Pressure Gauge, 6 bar MAT3-D20.B20
Brand: Bourdon
SKU: 145277
Price: 14.93 USD
Availability: InStock



Category Pressure Gauges Brand Bourdon Condition New

Specifications

Country of Origin	China
Accuracy	±2.5 %
Brand	Bourdon
Model	MAT3-D20.B20
Connection Type	Bottom
Case Material	Black Painted Steel
Series	MAT
Maximum Operating Temperature	70°C
Dial Size	63mm
Connection Size	G 1/4
Standards/Approvals	EN 837-1, PED 97/23/CE
Maximum Pressure Measurement	6bar
Minimum Pressure Measurement	0bar
Connection Location	Bottom Entry
Dial Colour	White

Key Features

Features a black painted steel case for durability.
Equipped with a bottom G 1/4 connection type and size.
Offers an accuracy of ±2.5% for reliable pressure readings.
White dial color with clear black graduations for easy readability.
Maximum operating temperature is 70°C for versatile applications.
Complies with EN 837-1 and PED 97/23/CE standards ensuring quality and safety.
Designed with a cupreous metal Bourdon tube and knife edge black aluminum pointer.
IP32 rated for protection against dust and water ingress.

Product Description

Bourdon MAT3-D20.B20 Pressure Gauge features a 63 mm dial size with a black painted steel case, a bottom G 1/4 connection, and a maximum pressure measurement of 6 bar. This gauge provides an operating temperature limit of 70°C and an accuracy of ±2.5%, making it suitable for various industrial and commercial applications requiring precise pressure monitoring.

The gauge dial is white with easy-to-read black graduations and a knife edge black aluminum pointer that enhances legibility. Its construction includes a cupreous metal Bourdon tube and a welded tube connection assembly, contributing to its reliability and durability.

This pressure gauge is IP32 rated, providing protection against dust and water penetration, making it suitable for environments where such exposure is possible. It meets the EN 837-1 and PED 97/23/CE standards, ensuring compliance with industry safety and performance regulations.

Ideal for use in compressed gases, lubricating circuits, hot or cold water networks, and water distribution systems, this gauge ensures accurate pressure measurement in diverse settings. The bottom entry connection type simplifies installation in tight spaces.

Manufactured in China, this product combines quality materials and precise engineering to deliver consistent and reliable performance. The Bourdon MAT series features multiple dial sizes including 40, 50, 63 mm and 100 mm variants.

Features a black painted steel case for durability. Equipped with a bottom G 1/4 connection. Offers an accuracy of ±2.5% for reliable readings. White dial with clear black graduations improves readability. Maximum operating temperature of 70°C for versatile use.

Complies with EN 837-1 and PED 97/23/CE quality standards. Includes a cupreous metal Bourdon tube and knife edge pointer. Labeled as IP32 rated for dust and water protection. Suited for compressed gases and water network pressure monitoring.

Manufactured in China ensuring consistent quality. Browse similar industrial Pressure Gauges and Bourdon products at EnvMart for your mechanical and fluid power instrumentation needs.
