Molex 5 Way Female PicoBlade to 5 Way Female PicoBlade Wire to Board Cable 125V 100mm 15134-0501

Molex 15134-0501 Wire to Board Cable is a 5 Way Female PicoBlade to 5 Way Female PicoBlade connector assembly with a 100 mm length designed for compact and reliable electronic interconnections. Rated at 125 V, this cable features a phosphor-bronze contact material with tin plating to maximize signal integrity and prevent corrosion.

The cable assembly is constructed using UL1061 discrete wires and insulated with a black polyester sheath that offers excellent electrical insulation and mechanical protection. Its compact design with 1.25 mm pitch connectors makes it ideal for prototype designs and production applications requiring secure and space-efficient wiring solutions.

Friction locks on the connectors prevent accidental unmating, ensuring stable connections even in environments subject to vibration or handling. This product performs reliably within a wide temperature range of -40°C to +85°C, making it suitable for industrial, medical, gaming, and mobile device applications.

Compatible with Molex PicoBlade wire to board PCB headers from Series 53261, 53047, 53398, and 53048, this cable is well-suited for electrical and electronic assembly needs where precise and secure connections are mandatory.

The cable features two 5-contact female PicoBlade connectors with 1.25 mm pitch for space-saving PCB connections. Constructed with phosphor-bronze contacts and tin plating to ensure reliable, long-term signal transmission.

Cable length is 100 mm with a black polyester jacket for insulation and protection. Rated for 125 V operation and suitable for gaming consoles, medical devices, and mobile devices. Equipped with friction locks to prevent accidental disconnections during use.

Operating temperature range from -40°C to +85°C ensures performance in demanding conditions. Compatible with Molex PicoBlade PCB headers Series 53261, 53047, 53398, and 53048. Explore more specialized Wire to Board Cable assemblies and connectors in the Electronics & Electricals category at EnvMart for enhanced prototype and production applications.
