Molex Wire to Board Cable 8 Way Female PicoBlade to 4 Way Female PicoBlade 150 mm 125V 15134-0402
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 125V |
| Brand | Molex |
| Cable Length | 150mm |
| Series | 15134 |
| Standards/Approvals | UL1061, ISO- and TS-16949, 2011/65/EU RoHS |
| Connector Type A | PicoBlade |
| Connector Gender A | Female |
| Jacket Colour | Black |
| Number of Contacts A | 8 |
| Number of Contacts B | 4 |
| Number of Rows A | 1 |
Key Features
- Features robust PicoBlade connectors with 1.25 mm pitch for compact space saving installation.
- Durable thermoplastic housing offers impact resistance suitable for harsh environments.
- Cable length of 150 mm allows flexible connections in tight spaces.
- Supports a voltage rating of 125V and current rating of 1A for standard low-voltage uses.
- Tin-plated contacts ensure corrosion resistance and longer component lifespan.
- Includes vibration-proof friction locks to secure the connectors firmly on PCB headers.
- Constructed using UL1061 discrete wires for reliable design and prototyping.
- Compatible with Molex PicoBlade Series 15134 wire-to-board connectors and headers.
Product Description
Molex 15134-0402 Wire to Board Cable is a high-quality cable assembly featuring an 8 Way Female PicoBlade connector to a 4 Way Female PicoBlade connector, connected by a 150 mm black cable. It is engineered for low-voltage circuit board connections with a voltage rating of 125V and designed to meet UL1061, ISO- and TS-16949, and 2011/65/EU RoHS standards. The thermoplastic connector housings provide durability and resistance to impact, making this cable suitable for demanding industrial, medical, and commercial applications.
The 1.25 mm pitch PicoBlade connectors allow for compact and space-saving wire-to-board connections, while the pin-to-pin map technology simplifies signal allocation. Tin contact plating enhances corrosion resistance, ensuring longevity and stable electrical connections even under vibrations thanks to the friction lock feature. The discrete UL1061 wire construction eases integration during design and prototyping phases.
This cable assembly is widely used in industries such as medical instrumentation, gaming consoles, and consumer electronics. It facilitates organized wiring solutions by bundling the wires into a single assembly, improving reliability and reducing installation time.
Robust PicoBlade connectors with 1.25 mm pitch for dense PCB connections. Durable thermoplastic housing for impact resistance. 150 mm cable length suitable for compact setups. Supports 125V voltage and 1A current rating for safety and performance.
Tin-plated contacts resist corrosion and ensure longevity. Vibration-proof friction lock secures connection to PCB headers. UL1061 discrete wire construction simplifies design and prototyping. Compatible with Molex Series 15134 PicoBlade headers.
Perfect for applications in medical, gaming, and home entertainment.
Choose Molex wire-to-board cable assemblies from EnvMart to ensure high-quality and reliable PCB interconnections. Explore the full range of connectors and cables designed for industrial and commercial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The cable supports a voltage rating of 125V and a current rating of 1A for standard low-voltage applications.
The cable length is 150 mm, allowing for flexible connections in tight spaces.
It features an 8 Way Female PicoBlade connector on one end and a 4 Way Female PicoBlade connector on the other end.
This cable complies with UL1061, ISO- and TS-16949, and 2011/65/EU RoHS standards.
The connectors are made from durable thermoplastic housing, providing impact resistance suitable for harsh environments.
It includes vibration-proof friction locks that secure the connectors firmly on PCB headers, enhancing connection stability.
The PicoBlade connectors have a pitch of 1.25 mm, allowing for compact space-saving installations.
The country of origin for this cable is India.
The cable features a black jacket color.
It is widely used in industries such as medical instrumentation, gaming consoles, and consumer electronics.
The 8 Way Female connector has 8 contacts, while the 4 Way Female connector has 4 contacts.
It is constructed using UL1061 discrete wires, which simplifies design and prototyping.
