STMicroelectronics DSI to HDMI Adapter Board for ST Discovery Kits B-LCDAD-HDMI1
Specifications
| Country of Origin | India |
|---|---|
| Resolution | 480 x 800 pixels (WVGA) |
| Display | 4in TFT LCD touchscreen display |
| Brand | STMicroelectronics |
| Model | B-LCDAD-HDMI1 |
| Interfaces | lanes of MIPI/DSI data, each running up to 800 Mbps |
| Accessory Type | DSI to HDMI Adapter Board |
| For Use With | ST Discovery Kits |
| Standards/Approvals | HDMI v1.3 |
Key Features
- The board supports 2-, 3-, or 4-lane MIPI DSI video input with data rates up to 800 Mbps per lane.
- Integrates the ADV7533 bridge chip for HDMI v1.3 compliant output.
- Supports audio input via S/PDIF and 2-channel I2S stereo audio up to 192 kHz sampling rate.
- Suitable for development and embedded design applications with STM32 Discovery Boards.
- Includes protection features such as common-mode filters and ESD protection.
- Supports video resolutions with pixel clocks up to 80 MHz and CEC signals.
- Features 5 V-tolerant I2C and HPD input/output pins for HDMI interface control.
Product Description
STMicroelectronics B-LCDAD-HDMI1 is a high-performance DSI to HDMI adapter board specifically designed for STM32 Discovery Boards used in development and embedded applications. Featuring a bridge chip ADV7533, this adapter supports 2-, 3-, or 4-lane MIPI/DSI video input data streams, with each lane capable of running at up to 800 Mbps, ensuring high-quality video transmission.
The board supports HDMI v1.3 output, facilitating the connection of Discovery boards to HDMI-compliant displays. It also transmits stereo audio via 2-channels I2S audio at sampling rates up to 192 kHz and supports S/PDIF for stereo LPCM or compressed audio formats.
Designed for embedded and development design use cases, the B-LCDAD-HDMI1 adapter is equipped with essential features such as common-mode filters and electrostatic discharge (ESD) protection, providing robustness and reliability in demanding environments. It supports video resolutions up to pixel clocks of 80 MHz and includes support for HDMI CEC signals, facilitating consumer electronics control.
The 5 V-tolerant I2C and Hot-Plug Detect (HPD) input/output pins provide reliable control interface connectivity. This accessory is essential for developers utilizing ST Discovery kits aiming to integrate HDMI interface capabilities in their embedded systems.
Options for interfacing with other display modules include the B-LCD40-DSI1 capacitive touchscreen and related adapters, complementing the B-LCDAD-HDMI1 board. It is a critical accessory for electronics, power connectors, and development tool peripherals utilized in STEM education, embedded systems, and rapid prototyping.
The board supports 2-, 3-, or 4-lane MIPI DSI video input at up to 800 Mbps per lane. Includes the ADV7533 bridge chip enabling HDMI v1.3 output. Supports stereo audio transmission with I2S audio input up to 192 kHz and S/PDIF input.
Facilitates video resolutions handling and supports CEC signals for HDMI devices. Equipped with protection features like common-mode filters and ESD protection. Provides 5 V-tolerant I2C and HPD I/Os for HDMI control interfaces.
This adapter board expands the capabilities of STM32 Discovery Kits for development in embedded, electronic, and display interface applications. Explore further compatible development tools and accessories within EnvMart’s Electronics & Electricals category.
Explore more products in our Development Tool Accessories category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The adapter board supports MIPI DSI video input with data rates up to 800 Mbps per lane, accommodating 2-, 3-, or 4-lane configurations.
It complies with HDMI v1.3 standards, facilitating connections to HDMI-compliant displays.
The adapter supports stereo audio transmission via S/PDIF and 2-channel I2S audio at sampling rates up to 192 kHz.
It supports video resolutions with pixel clocks up to 80 MHz, allowing for various display configurations.
It includes common-mode filters and ESD protection to ensure reliable operation in demanding environments.
This adapter supports MIPI DSI data streams, allowing for flexible interfacing with various display modules.
Yes, it is specifically designed for development and embedded applications with STM32 Discovery Boards.
It features 5 V-tolerant I2C and Hot-Plug Detect (HPD) input/output pins for HDMI interface control.
The country of origin for this adapter board is India.
It is compatible with a 4-inch TFT LCD touchscreen display, enhancing user interaction in embedded systems.
The model number of this adapter board is B-LCDAD-HDMI1, which is used for identification and compatibility purposes.
It is designed for use with ST Discovery Kits, expanding their capabilities for various applications.
